Specifications
100w led industrial light:1 Good heat dissipation
2 High brightness
3 3 years warranty
4 Mean Well driver
explosion proof led high bay light100w for factory lighting details
1. All adopt Bridgelux LED chip and Mean Well or BEEQOO driver .
2. Lumen efficiency of leds can be 115-125Lm/W.
3. Passed CE, RoHS, FCC, EMC certifications.
4. We have patent on the design.
5. 3 years warranty for Mean Well driver, 2 years for BEEQOO driver, 5 years for LED chip.
6. Emitting colors available: warm white, pure white, cool white, red, yellow, green, blue, RGB etc.
Our line of industrial LED high bay lights is available from 30 to 400w,in various forms and with different reflectors.
The protection class is from IP54 to IP68.CCT from 2500k to 7000k.Product without glass for the food industry is an available option.Beam Angle are 45°, 90°and 120°.
explosion proof led high bay light100w for factory lighting applications
Applications areas: workshop,factory building,warehouse,highway toll stations,gas stations,suppermarkets,exhibition halls,stadiums and other places of lighting required.
100w led insustrial light with SAA TUV 100w led insustrial light with SAA TUV
explosion proof led high bay light100w for factory lighting specifications
| Item No. | BQ-GK515-100W | |||
| Power | 100W | |||
| Input voltage | AC85-265V/50-60Hz | |||
| LED source | Bridgelux 45mil G1 | |||
| LED QTY | 1PCS | |||
| Total harmonic distortion | ≤9% | |||
| Power factor | >0.98 | |||
| LED efficiency | 115-125Lm/W | |||
| LED light luminous efficiency | 100-105Lm/W | |||
| Color temperature | WW: 2700-3500K | |||
| PW: 4500-5500K | ||||
| CW: 6000-7000K | ||||
| CRI(Ra) | >70 | |||
| IP grade | IP65 | |||
| LED junction temperature | ≤70°C | |||
| Ambient temperature | -40°C—45°C | |||
| Material | Aluminium + tempered glass | |||
| Lifepsan | 50,000hrs | |||
| Warranty | 3years | |||
| Certification | CE/RoHS/FCC/EMC/LVD | |||
| Net/Gross weight | 6.22kg/6.78kg | |||
Certifications
Additional information
1. OEM and ODM are availble.
2. Your inquiry will be replied within 24 hours by experienced staff.
3. Specific models with unique design can be done on demand and exclusively reserved to your distribution.
4. Detailled cooperation framework can be done case by case to preserve confidentiality and ensure long term partnership.
Visit our website . Do not hesitate to come in our factory or to meet us during our next exhibition.
Product Description:
1 Light source:
Aluminium Nitride Ceramic. The junction temperature of patented LED enclosed in ceramic is 5 Celsius degree, lower than that of standard LED. High light efficiency, low light degradation, stand higher temperature than traditional LED.
2 Power supply:
Have the relationship with Meanwell , ensuring the uniformity and reliability of the products' quality. Specially designed driver for high bay light, using Japanese Rubycon capacitor, provide high power factor and power efficiency. Meanwell brand driver is used for the lights over 100w.
Light distribution and lux distance curve.
3 Heat sink design:
This heat sink have much more heat dissipation surface compared to the traditional Die casting one, it is good for radiating the heat of LED to the surrounding environment by making full use of cross-ventilation, ensuring LED chip work at a safe condition and reducing ight degradation.
4 Heat dissipation:
Adopting the association scheme of heat pipe and Aluminium profile, making the calorigenic lighting source transfering to the radiators terminal fast. Then the super area fin via its function of cross-ventilation to radiant thermal to the surrounding environment.
Trade Terms:
1. Payment:T/T,Western Union, Paypal.
2.Shipping term up to your choice.
3.By Express(Door to door):DHL ,UPS ,TNT ,Fedex.By Air ,By sea are optional.
4.Shipping port: Shenzhen, Mainland China.
5.Discounts are offered based on order quantities.
Warranty:
We promise you 3 years warranty. If the products do not work during this period, we shall replace them total free and the express cost is to be borne at our side.
Any feedback from you will be much appreciated.
