Help CenterAudio Amplifier
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JBSYSTEMS
Model Number:
AMP 100.2
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
JBSYSTEMS
Model Number
AMP 100.2
Specifications
Item: Professional audio amplifier1.Short Circuit protection
2.DC current protection
3.High temperture protection
Description
- Professional 2-channel power amplifier
- Extremely compact 19" housing, height only 1U (44mm)
- Lightweight design based on soft start switch mode power supply
- 3 amplifier modes: stereo, mono and bridge
- Very efficient cooling, using temperature controlled fans.
- Peak limiter prevents signal distortion
- Switchable 75Hz / -24dB low cut filter
- Adjustable input sensitivity: 0,775V ~ 1,0V ~ 1,44V
- Ground lift switch
- DC fault + high temperature + overload and short circuit protections
- Balanced XLR-inputs & jack-outputs: daisy chaining of several amplifiers
- 3 Speakon® outputs: left + right channels + bridge
Technical Information
- Power stereo 4Ohm: 2x 100Wrms
- Power stereo 8Ohm: 2x 70Wrms
- Power bridge 8Ohm: 1x 200Wrms
- Peak limiters: yes
- Freq. Response (+/-1dB): 20-20.000Hz
- Input sensitivity: 0,775V~1,0V~1,44V
- S/N ratio: >100dB
- Weight: 4,5kg
- Dimensions: 483x235x44 (19" / 1U)
