Factory Wholesale 316L Stainless Steel Pipe,202 Grade Stainless Steel Pipe

Name: Factory Wholesale 316L Stainless Steel Pipe,202 Grade Stainless Steel Pipe
Brand: XIANGDANGDANG
SKU: 114283485

US$ 1 - 3,000 MOQ: 1 Ton

Key Specifications

Standard:

ASTM, AISI

Place of Origin:

Guangdong, China

Brand Name:

XIANGDANGDANG

Foshan Xindongyuan Stainless Steel Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou port

Delivery Detail:

Delivery time depends on order quantity.

Standard ASTM, AISI

Place of Origin Guangdong, China

Brand Name XIANGDANGDANG

Model Number ASTM-A554

Type Welded

Steel Grade 200 Series

Application decration

Certification ISO

Welding Line Type Spiral Welded

Thickness 0.2mm~5.0mm

Outer Diameter 8mm~254mm

Name	Factory Wholesale High Quality 316L/202 grade stainless steel pipe
Standard	ASTM A554, A249, A269 and A270, A312
Material Grade	201 ( Ni 0.8%), 202 (Ni 3.5%~4.5%), 301(Ni 5%) 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L (Ni10%~14%),
Outer Diameter	6mm--159mm
Thickness	0.3mm - 3.0mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/- 0.2mm
	b) Thickness: +/- 0.02mm
	c) Length: +/- 5mm
Surface	180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish
Application	Decoration construction, upholstery, industry instrument
Test	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Chemical Composition of Material	Material Composition	201	202	304	316	430
	C	≤0.15	≤0.15	≤0.08	≤0.08	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	16-18	17-19	18-20	16-18	16-18
	N	3.5-5.5	4-6	8-10.5	10-14
	Mo				2.0-3.0
Mechanical Property	Material Item		201	202	304	316
	Tensile Strength		≥535	≥520	≥520	≥520
	Yield Strength		≥245	≥205	≥205	≥205
	Extension		≥30%	≥30%	≥35%	≥35%
	Hardness (HV)		<253	<253	<200	<200
