Stainless Steel Pipe Stainless Steel Hollow Ball

Name: Stainless Steel Pipe Stainless Steel Hollow Ball
Brand: xiangdangdang
SKU: 114284183

US$ 1,000 - 5,000 MOQ: 5 Tons

Key Specifications

Standard:

JIS, AISI, ASTM, GB, DIN, EN, Other, JIS, AISI, ASTM, GB, DIN, EN, ASTM A554

Place of Origin:

Guangdong, China

Brand Name:

xiangdangdang

Foshan Xindongyuan Stainless Steel Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou / Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Standard JIS, AISI, ASTM, GB, DIN, EN, Other, JIS, AISI, ASTM, GB, DIN, EN, ASTM A554

Place of Origin Guangdong, China

Brand Name xiangdangdang

Model Number ASTM A554

Type Welded

Steel Grade 300 Series

Application decoration, construction and upholstery, etc.

Certification ISO

Welding Line Type ERW

Thickness 0.16mm~3.0mm

Outer Diameter 5mm~219mm

Specifications

1.Material:201,202,304,316L,430,etc
2.OD:6mm-219mm
Thickness:0.25mm-3mm
3.Surface:Mirror,Satin/HL

stainless steel pipe stainless steel hollow ball

Suface:2B/BA/HAIRLINE/MIRROR ETC

Name	stainless steel hollow ball
Standard	ASTM A554, A249, A269 and A270, A312
Material Grade	201 ( Ni 0.8%), 202 (Ni 3.5%~4.5%), 301(Ni 5%) 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L (Ni10%~14%),
Outer Diameter	6mm--159mm
Thickness	0.3mm - 3.0mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/- 0.2mm
	b) Thickness: +/- 0.02mm
	c) Length: +/- 5mm
Surface	180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish
Application	Decoration construction, upholstery, industry instrument
Test	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Chemical Composition of Material	Material Composition	201	202	304	316	430
	C	≤0.15	≤0.15	≤0.08	≤0.08	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	16-18	17-19	18-20	16-18	16-18
	N	3.5-5.5	4-6	8-10.5	10-14
	Mo				2.0-3.0
Mechanical Property	Material Item		201	202	304	316
	Tensile Strength		≥535	≥520	≥520	≥520
	Yield Strength		≥245	≥205	≥205	≥205
	Extension		≥30%	≥30%	≥35%	≥35%
	Hardness (HV)		<253	<253	<200	<200
