Place of Origin Guangdong, China
Brand Name EMEIS
Model Number Customized
Usage Audio
Phase Single
Coil Structure Other, Toroidal, Toroidal
Coil Number Autotransformer

Specifications

1.Frequency: 50 to 60Hz
2.Power factor: 0.9 to 0.98
3.Efficiency: 75 to 98%
4.Voltage regulation: 12 to 3%

8VA to 30kVA Toroidal Transformer with 0.5 to 10.0W No-load Output and 75 to 98% Efficiency



Key Specifications/Special Features:

  • Features:
    • 100% QC from raw material to finished products
    • Reliable performance and safety
    • Small volume and low weight
    • Low mechanical hum
    • Good shielding performance, low magnetic leakage
    • Dimension adjusted freely
    • Easy to mount and fasten
    • Excellent workmanship
  • Specifications:
    • Capacity: 8VA to 60kVA
    • Phase: single
    • Input voltage: AC power with voltages of various countries
    • Output voltage: AC or customized
    • Frequency: 50 to 60Hz
    • Power factor: 0.9 to 0.98
    • Efficiency: 75 to 98%
    • Voltage regulation: 12 to 3%
    • Output no-load loss: 0.5 to 10.0W
    • Temperature-rise: ≤85°C
    • Insulation class:
      B: 130°C
      E: 120°C
    • Testing items:
      • No-load test (no-load current, voltage and loss)
      • Load test (load voltage, temperature-rise)
      • Inductive voltage test
      • DC resistance test
      • Safety test
    • Key parts:
      • Core: wound by high quality cold grain silicon, annealed by advanced vacuum annealing furnaces to improve electronic data, any dimension from customer are available
      • Wire: copper and aluminum are available
      • Weld aluminum enamel wire well to save your cost 15 to 35%, based on our know-how technology
      • Thermal protector: cutoff and switch are both available
    • Applications:
      • Electronic meter and apparatus
      • Cable TV and digital network
      • Electronic control
      • Medical equipment
      • New electric power supply
      • Decorative illumination system
      • Monitoring and control equipment
      • Installation: horizontal (non-conventional-type base plate), sunk, side type and bridge
    • Label info:
      • Certificate logo, basic electronic data, manufacturer's information also can be printed according to customer's request
      • Bar code is available based on customer's request

    8VA to 30kVA Toroidal Transformer with 0.5 to 10.0W No-load Output and 75 to 98% Efficiency8VA to 30kVA Toroidal Transformer with 0.5 to 10.0W No-load Output and 75 to 98% Efficiency



    OEM, ODM and Custom designed drawing and samples acceptable
    All data are subject to modification without notice in advance.
