Specifications
Mortar PumpPump and convery mortar;
Used for grouting in mine gallery, rail, road tunnel;
Single Cylinder Mortar Pump
What is Mortar Pump?
Introduction Of Mortar Pump
With its convenient maintenance, high working pressure and high efficiency, working reliability, compact structure etc,single cylinder acting. Mortar Pump can be used not only for grouting cement mortar and sand mortar, combined with accessories such as compressor and spraying gun, it is also ideal equipment applied in spraying. the mortar pump is widely used for grouting in mine gallery, rail and road tunnel, hydropower construction, slope consolidation, underground engineering, subway and civil engineering etc.
The SG5040 Mortar Pump have two kinds: basic electric drive,diesel engine drive.
Technical Parameters of Mortar Pump
Model: |
SG5040 |
Output |
50 L/min |
Cylinder Dia |
φ 90 mm |
Working Pressure |
4 MPa(40bar, 580psi) |
Piston stroke |
85 mm |
Piston Speed |
95 /min |
Inlet diameter |
75 mm |
Outlet diameter |
50 mm |
Max. Aggregate. size |
6 mm |
Cement/Sand |
≥ 1/3 |
Power |
5.5 kW(Electric)/10hp(Diesel) |
Overall Dimensions |
1610× 1024× 900 mm |
Weight |
300 kg |
Applications Of Mortar Pump
- Pumping or grouting mortar or the similar material.Such as Grouting cement mortar and sand mortar, combined with parts, compressor and spraying gun.
- Mortar Pump is used for grouting in mine gallery, rail and road tunnel, hydropower construction, slope consolidation, underground engineering, dam, foundation engineering of big bridge, subway and civil engineering etc.
Features of Mortar Pump
- Efficient and convenient operating performance
- Single piston single acting;
- Mechanical transmission, lower failure rate;
- Integrate pump head and hopper; prevent eduction and deposition together with the paddle agitating;
- Compact structure of Mortar Pump is convenient for maintaining and leaning
- Large flow, high efficiency, safety and reliability, easy to move, long life
Pump-head-assemble
Packaging of Mortar Pump: The wooden cases with international standard, free fumigation safe Wood case package.
Delivery time: 10-15 working days after the confirmation of the order.
FAQ:
1. How many people that need to operate the Mortar Pump?
One or two workers can use it successfully.
2. What is Max aggregate size ?
The size is 6mm
3. Available shipment port?
FOB SHANGHAI
FOB TIANJIN
FOB QINGDAO
4. How much is Mortar Pump price?
Compared with the same quality products, It's cheap! The specific price,we can talk it by email or skype.
5. Our company have some high quality Mortar Pump,do you want to to buy?
Contact me,I'll give a reasonable quotation.
More question, please contact me by following ways in time.
If you would like to some information about Mortar Pump.
contact me
Skype: sincolasale
