Specifications
Weichai engine for land useLow fuel consumption
Factory price with CE & ISO approved
High performance 125kva Weichai diesel generator
Weichai diesel generator set general feature:
1) Output range:27kw--200kw(250kVA)
2) Engine model: Weichai
3) Alternator: Stamford or Marathon or Lory somer is optional
4) Water-cooled
5) 8hrs operation base tank
6) Key start / auto start
7) silent generator is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wiresalternating current output
9) Frequency: <3%
10) Frequency at stable state: <0.5%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%15) Voltage return time: ≤4s16) Voltage modulation: ≤0.3%
Alternator Feature
Brush-less, 4 poles, rotation magnet.
IP21-23 (NEMA1) enclosure is standard for all industrial alternators.
The insulation system is Class H
Simple installation and maintenance, with easy access to terminals, rotating diodes
Wide range of flange adaptors and single bearing disc coupling.
Standard 2/3 pitch windings avoid excessive neutral currents
AVR auto voltage regulator, auto exciter, auto adjustment
Controller system
1. Standard control panel, including voltmeter, frequency meter, ampere meter, water temperature gauge, oil temperature gauge, oil pressure gauge, AMF control module, oil level indicator, emergency button, preheating button, battery voltage gauge, hours running counter for protection and transfer.
2. It can be with ATS electric control cabinet, including circuit breaker, LCD or LED auto controller, indicating lamp, transfer switch, etc. Automatic transfer switch (ATS) uses update technology, which can be automatic control for onoff electricity, remote monitoring, automatic parallel operation, etc.
Optional for diesel generator
- ATS (Automatic transfer system)
- Stand alone luxury fuel tank
- Parallel operation, synchronization system
- Remote control starting
- Soundproof canopy Diesel generator
- Weatherproof canopy Diesel generator
- Containerized Diesel generator
- Trailer Diesel generator
ATS means Automatic Transfer Switch, when the city power supply failure, the genset will be running
automatically within few minutes. on the contrary, when the city power recovered, the genset will stop
running automatic by itself within few minutes.
Weichai generator specification
| 3P 4W | Diesel Engine | Alternator | Overall Size (mm) | Weight (kg) |
| Rated Power (kW/kVA) | Model | Model | ||
| 16/20 | D226B-3D | PI144D | 1600X600X1350 | 650 |
| 20/25 | D226B-3D | PI144E | 1600X600X1350 | 660 |
| 22/28 | D226B-3D | PI144F | 1600X600X1350 | 680 |
| 24/30 | D226B-3D | PI144G | 1650X650X1400 | 700 |
| 28/35 | TD226B-3D | PI144H | 1650X650X1400 | 700 |
| 32/40 | TD226B-3D | PI144J | 1650X650X1400 | 700 |
| 34/43 | TD226B-3D | PI144K | 1650X650X1400 | 750 |
| 40/50 | TD226B-3D | UCI 224D | 1900X650X1400 | 800 |
| 48/60 | TD226B-4D | UCI 224E | 2700x820x1500 | 1000 |
| 58/73 | TD226B-6D | UCI 224F | 2700x820x1500 | 1000 |
| 68/85 | TD226B-6D | UCI 224G | 2700x820x1500 | 1300 |
| 80/100 | TD226B-6D | UCI 274C | 2700x820x1500 | 1300 |
| 96/120 | TBD226B-6D | UCI 274D | 2700x820x1500 | 1300 |
| 112/140 | TBD226B-6D5 | UCI 274E | 2800X850X1550 | 1350 |
| 128/160 | TBD226B-6D5 | UCI 274F | 2850X900X1600 | 1380 |
| 145/181 | BF6M1013EC | UCI274G | 2900X945X1750 | 1420 |
| 160/200 | BF6M1013FCG2 | UCI274H | 3100X1190X1890 | 1700 |
| 184/230 | BF6M1013FCG3 | UCI274J | 3250X1190*1900 | 1800 |
Weifang diesel generator sale
Packing
Wooden case or plywood case
Any question,pls contact with me directly.
Remark:Control panel(including Automatic protection):low and high frequency,low oil pressure protection and high water temperature protection
Terms of Warranty
1. Since genset reached the agreed destination, its main parts will be guaranteed within 12 months or 1000 hours.
2. We take charge of all troubles caused by genset’s fault and repair according to the regulation stipulated by original plants.
3. Factors not accordance with the regulation of original plants such as fagile parts, daily consumed components, wrong operating, lack of maintenance are not included in the quality guarantee.
About us
Fujian Disaier Power System Co., Ltd. specializes in providing Power Supply Solution as diesel generator sets. In the past 10 years, over 600 customers have been benefited from the reliable generator sets we provided. With our professional team, quality equipments and always intime postsale service, we have earned good reputation in the industry.
Invitation to visit to our factory
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China.
2. Our factory locates in Nanan City, which is famous for its stone , is just 45 minutes away from Xiamen.
3. When you come to Xiamen, we can send cars to pick you up and take you to our factory.
4. In the factory we can discuss more about the cooperation and we will listen to your requirements.
For more detail information,pls feel free to contact with us.
