Specifications
250kva diesel generatorWeichai engine for land use
Low fuel consumption
Factory price with CE & ISO approved
250kva weichai diesel generator for sale
Weichai generator specification
| 3P 4W | Diesel Engine | Alternator | Overall Size (mm) | Weight (kg) |
| Rated Power (kW/kVA) | Model | Model | ||
| 16/20 | D226B-3D | PI144D | 1600X600X1350 | 650 |
| 20/25 | D226B-3D | PI144E | 1600X600X1350 | 660 |
| 22/28 | D226B-3D | PI144F | 1600X600X1350 | 680 |
| 24/30 | D226B-3D | PI144G | 1650X650X1400 | 700 |
| 28/35 | TD226B-3D | PI144H | 1650X650X1400 | 700 |
| 32/40 | TD226B-3D | PI144J | 1650X650X1400 | 700 |
| 34/43 | TD226B-3D | PI144K | 1650X650X1400 | 750 |
| 40/50 | TD226B-3D | UCI 224D | 1900X650X1400 | 800 |
| 48/60 | TD226B-4D | UCI 224E | 2700x820x1500 | 1000 |
| 58/73 | TD226B-6D | UCI 224F | 2700x820x1500 | 1000 |
| 68/85 | TD226B-6D | UCI 224G | 2700x820x1500 | 1300 |
| 80/100 | TD226B-6D | UCI 274C | 2700x820x1500 | 1300 |
| 96/120 | TBD226B-6D | UCI 274D | 2700x820x1500 | 1300 |
| 112/140 | TBD226B-6D5 | UCI 274E | 2800X850X1550 | 1350 |
| 128/160 | TBD226B-6D5 | UCI 274F | 2850X900X1600 | 1380 |
| 145/181 | BF6M1013EC | UCI274G | 2900X945X1750 | 1420 |
| 160/200 | BF6M1013FCG2 | UCI274H | 3100X1190X1890 | 1700 |
| 184/230 | BF6M1013FCG3 | UCI274J | 3250X1190*1900 | 1800 |
Weichai diesel generator set general feature:
1) Output range:27kw--200kw(250kVA)
2) Engine model: Weichai
3) Alternator: Stamford or Marathon or Lory somer is optional
4) Water-cooled
5) 8hrs operation base tank
6) Key start / auto start
7) silent generator is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wiresalternating current output
9) Frequency: <3%
10) Frequency at stable state: <0.5%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%15) Voltage return time: ≤4s16) Voltage modulation: ≤0.3%
Alternator
1)Optional Brand: Engga, Stamford, Marathon,Leroy-Somer …
2)The standard generator set matches with Engga brand alternator, and customer also can choose other brands.
3)Standard AVR, AC three phase, 12 reconnect copper leads, single bearing or double bearing, self-exciting system and permanent magnet generator.
4)IP2123 protection grade, insulation system is H class, and stators are wound to 2/3 pitch.
5)Manufacture standards: GB755, BS5000,VDE0530,NEMAMG122,IEC34,and ASB59
Optional Brand: Smartgen,Deepsea,Comap
It includes the following:
1. Automatic cutter which is suitable for the generator power
2.Turn on key
3.A device to measure the generators speed
4.Counter for measuring the Operating hours
5.Device to measure the current overload with a switched current
6.A device to measure the battery voltage
7.Voltmeter with a voltage exchanger
8.A device to measure the frequency
9.Thermostat to regulate the voltage
10.A device to measure the oil pressure
11.Alerting lamps indicating low and high temperature
12.Controller of the current increase and short circuit
13.Emergency stop button
ATS means Automatic Transfer Switch, when the city power supply failure, the genset will be runningautomatically within few minutes. on the contrary, when the city power recovered, the genset will stoprunning automatic by itself within few minutes.
Weifang diesel generator sale
Warranty
Guarantee for one year or 1000 hours (accord to whichever reach first) from exfactory date.During the guarantee period,our company will provide the free easy damaged spare part for problems caused by our quality&nbsx;of production or raw material except the damageable spare parts of diesel engine caused by customer's incorrect man made operation.After expiration, our company provides cost parts maintenance for genset.
Advantages
1)Function stability credibility, service convenience;
2)Low operating cost results in optional economy;
3)Gets the job done wherever you are;
4)Ease of installation, operation and maintenance.
About us
Fujian Disaier Power System Co., Ltd. specializes in providing Power Supply Solution as diesel generator sets. In the past 10 years, over 600 customers have been benefited from the reliable generator sets we provided. With our professional team, quality equipments and always intime postsale service, we have earned good reputation in the industry
Invitation to visit to our factory
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China.
2. Our factory locates in Nanan City, which is famous for its stone , is just 45 minutes away from Xiamen.
3. When you come to Xiamen, we can send cars to pick you up and take you to our factory.
4. In the factory we can discuss more about the cooperation and we will listen to your requirements.
For more detail information,pls feel free to contact with us.
