Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > LOVOL 1003G Generator Diesel Sets Price

LOVOL 1003G Generator Diesel Sets Price

Name: LOVOL 1003G Generator Diesel Sets Price
Brand: LOVOL
SKU: 114541103

LOVOL 1003G Generator Diesel Sets Price thumbnail-1

LOVOL 1003G Generator Diesel Sets Price photo-1

US$ 4,480 - 4,750 MOQ: 1 Unit

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

LOVOL

Model Number:

DL56GF

Contact Supplier Request Quote Chat Now

Xiamen Huadong Machine Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name LOVOL

Model Number DL56GF

Output Type AC Three Phase

Speed 1500/1800RPM

Frequency 50/60HZ

Rated Power 24KW/30KVA

Rated Voltage 220/380V,230/400V;220/440V,240/480V

Rated Current 55AMP

Specifications

1. For industry
2. Low oil consumption
3. Convenient to operate
4. High reliability, easy maintenance
5. OEM Certificates

30kva Lovol Diesel Generator Set data

Manufacturer:	Disaier Electrical Equipment Co., Ltd
Prime Power	24kw/70kva
Frequency/Speed	50hz/1500rmp
Dimension (LWH)	1620×610×1380mm
Net weight	610kg
Engine Model	1003G
Alternator Model	Leroy-somer
Controller model	Smartgen HGM6120K
Fuel consumption of 100% load	6.3 Litres/h
Fuel consumption of 75% load	4.7 Litres/h
Voltage regulation rate	≤±1%
Random voltage variation	≤±1%
Random frequency variation	≤±0.5%

Lovol Engine data

Brand / Model:	LOVOL, 1003G, 4-cycle
Air Intake System:	Natural Aspirated
Fuel System:	Direct type fuel pump
Cylinder Arrangement:	" L" type, 3-cylinder
Delivery Capacity:	3L
Bore and Stroke:	100*127(mm)
Compression Ratio:	16.5: 1
Rated Hz/RPM:	50Hz/1500rpm
Max. Standby Power at Rated:	30.8KW/41.9HP
Governor Type:	E
> Exhaust System
Exhaust Gas flow:	4.27m 3 /min
Exhaust Temperature:	410 centigrade
Max Back Pressure:	10 kPa
> Air Intake System
Max Intake Pressure:	6.25kPa
Consumption:	1.98 m3/min
Air Flow:	136 m3/min
> Fuel System
100%( Prime Power) Load:	6.3 L/h
75%( Prime Power) Load:	4.7 L/h
50%( Prime Power) Load:	3.2 L/h
> Oil System
Total Oil Capacity:	11 L
Oil Consumption:	≤ 4 g/kw. h
Engine Oil Tank Capacity:	9L
oil Min-Pressure at Rated RPM:	350kPa
> Cooling System
Total Cool fluid Capacity:	20 L
Thermostat Temperature:	82-93centigrade
Max Water Temperature:	104 centigrade

Alternator data

Brand / Model:	Leroy somer, Stamford or Marathon
Number of Phase:	3
Connecting Type:	3 Phase and 4 Wires, “ Y” type connecting
Amount of Bearing:	1
Power Factor:	0.8
Protection Grade:	IP23
Altitude:	≤ 1000m
Rated Hz/RPM:	50Hz/1500rpm
Exciter Type:	Brushless, self-exciting
Voltage control mode:	AVR(Automatic Voltage Regulator)
Insulation Class, Temperature Rise:	H/H
Radio interference:	Meet the BS800 and VDE G, N
Telephone Influence Factor (TIF):	< 50
Telephone harmonic Factor (THF):	< 2%
Steady Voltage adjustment rate:	≤ ± 1%
Generator Capacity:	25KW/31KVA
Generator Efficiencies:	86.20%
Standard Temperature Rise:	125 -163° C Continuous
Cooling method:	Direct drive centrifugal blower fan
Air Cooling Flow:	0.15 m³ /s

Generator Supply Scope

1.Engine, alternator, radiator, auto control panel.

2.Base frame, base fuel tank,Flexible pipes, flange, exhaust silencer .

3.Battery, battery charger, battery wires, internal cables, circuit breaker.

4.Manual books of engine, alternator, genset, control panel, wires diagram

Controller :Smartgen brand HGM6120K (standard)

Feature:

protection: Automatic start/stop, load transfer and alarming of generator;
Three channel analog inputs, may joint with Resistive-type temperature/ pressure/ fuel level sensors, Several temperature and pressure sensors can be used directly (ie. VDO, DATCON, CUMMINS), also may select “user defined” sensor via entering 8 point curves;
Display of generator cumulated electric energy;
Security password-protected programming levels.
Several crank success conditions are optional;
Power supply range is wide, accommodating to different starting battery voltage environments;
All parameters use digital modulation, abandoning analog modulation using conventional electronic potentiometer, reliability and stability are increased;
Built-in watch dog can never be dead halt, ensuring smooth program execution

Parameter:

Generator Volts, Amps, Frequency, active power, apparent power , power factor, Engine Oil Pressure, battery volt, Engine speed, engine temperature, Engine Hours Run, fuel level.

Protection:

1.Low Oil Pressure 2.High voltage and low voltage 3. Volt adjuster and frequency adjuster

4.Overspeed 5. Emergency stop 6.Fail to start 7. High Engine Temperature

cummins diesel genset

Lovol genset

Genset in stock

ATS FOR OPTION

canopy for option (soundproof ,weatherproof)

DSE controller for option

Marathon alternator

CE certificate approved

ISO9001 Approved

ISO1004 Approved

Leroy-somer OEM

ENGGA OEM

CE and IAF

Our promise

Pre-sales guidance:

Disaier Company professional technician responsible for users’ technical advisor question, make sure the configuration, features, optional items etc.

After-sales service:

Customers supreme, service-oriented

1 year or 1,500 running hours Quality Warranty, whichever comes first.

24 hours after-sales service telephone helpline. Within guarantee period if parts impaired, Cost offer parts (within factory standard parts) and technical.
