XQ1450WA high quality universal milling machine
Product Description for XQ1450WA high quality universal milling machine
Features:
Brief introduction
1.It is a vertical-horizontal Universal Swivel Head Milling Machine
2.Rigid,rectangular table guidewaws.
3.Automatic feeds on x, y axes,motorized lifting and lowering of table on Z axes.
4.Haredened and groud table surface
5.Dirll press head swivele ±360°
6.rotary table 45 degrees
Product description
Table taper |
ISO40ISO50H |
Max milling cutter diameter (mm) |
125V100H |
Swivel angel milling head(°) |
±360° |
Range fo vertical/horizontal speed(r.p.m) |
35-1600V |
Distance from spindle nose to table(mm) |
150-550 |
Distance form spindle to column (mm) |
760 |
Table size(mm) |
1500×360 |
(XYZ)Table travel |
|
T-slot(number-width-distance)(mm) |
3/18/80 |
Main motor power(kw) |
3 |
Overall dimension(mm) |
1550×1670×1950 |
Weight(kg) |
2650/2850 |
Production&Workshop for XQ1450WA high quality universal milling machine
Packaging&Shipping for XQ1450WA high quality universal milling machine
Customer&Expo for XQ1450WA high quality universal milling machine
Companny information for XQ1450WA high quality universal milling machine
Lianyungang Linuo Machine Tool Co.,ltd is a leading high-tech enterprise and manufacture in China for High end machine tools, has strong technical team covering full technical field.
which is specializes in exporting all kinds of machinery,such as grinding machines,CNC machine centers,CNC & universal lathes,CNC & universal milling machines,radial drilling machines,and cnc wire cutting edm machines,bandsaw machines etc.
Lianyungang Linuo Trading Co.,ltd is a Import & Export company,which is the branch company for international business.
We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service.
Our services for XQ1450WA high quality universal milling machine
1. Technical support online service provided.
2. Technical files service provided.
3. On-site training service provided.
4. All of the questions will be replied within 24 hours
5. Warranty period: one year
During warranty period, if you have any parts broken because of qulity problem,we will supply to you free of charge by express.
Out of warranty period, if you have any question, you can contact with us, we will supply our best service to you.
