SRH99-1CNC Toroidal Transformer INVERTER COIL Winder Machine
1.The product pictures of winder machine
2. The product descriptions of winder machine
Storing slot size |
200x9x11mm |
Wire size |
0. 25-0.55mm |
Min. finished inner diameter |
25mm |
Outter diameter |
160mm |
Max. metal core height |
60mm |
Max.speed |
700turns/minute |
Power source |
220V 50Hz |
Machine size |
680X660X780mm |
Packing size |
780x860x730mm |
Net weight |
123kg |
Gross weight |
156kg |
3. The Product features of winder machine
1. the store wire rings made of high quality steel making, to avoid breaking wire
2. store wire length and winding turns to light sensor sensing,let the store wire length and the winding truns accuracy
3. winding wire of AC motors, adopt inverter-driven, stepless, arrange wire and winding wire can adjsut the same speed, you can double winding, and you can move around 3600 variable to continuous winding wire
4. computer controller can store group step sequence, permanently save memory,and support inquiries ,automatic inertial measurement and other advanced parameters
voltage regulator and voltage stabilizer toroidal CNC wire winding machine is on the basis of introducing of foreign technology, and according to the domestic transformer industry new workmanship requirements, researching and developing by ourselves, high precision, new type, current transformer dedicated toroidal winding machine. This machine is widely using for winding kinds of toroidal current transformer coils. Especially suitable for the small-lot, varieties wire coils winding.
