Home > Consumer Electronics > Audio & Sets > Professional Audio > 5 Inch Active Monitor Speaker

5 Inch Active Monitor Speaker

Name: 5 Inch Active Monitor Speaker
Brand: C-MARK
SKU: 114976223

5 Inch Active Monitor Speaker thumbnail-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

C-MARK

Model Number:

MS500

Contact Supplier Request Quote Chat Now

Shenzhen Bao Ye Heng Industrial Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name C-MARK

Model Number MS500

Specifications

compact structure, precise sound, wide directivity, strong magnetic shielding, very low frequency and excellent resolution

MS series loudspeaker is professional active monitor speaker of high fidelity reduction performance. With compact structure, precise sound, wide directivity, strong magnetic shielding, very low frequency and excellent resolution, it brings out world-class clear accurate sound. MS series monitor loudspeakers are equiped with digital and analogue signals of two kinds of input interfaces, is another step into digital era history of the monuments for monitor speakers. The component selection of the amplifier is not only to have top-notch performance to meet radio and television broadcast studio control room and other modern music production sound monitoring, but also for high-end clubs and high-end home theater sound playback no matter you are mixing for rigorous work or trying to seize the unique sonic details. MS series monitor speakers are restore the sound details as much as it could do.

Features:

1. Using high-fidelity power amplifier circuit

2. With balanced XLR analogue inputs and AES digital signal input interface.

3. With magnetic fluid cooled, elastic silk high frequency driver and polycarbonate film voice coil low frequency driver.

4. Electromagnetic shielding for HF and LF.

5. It reduces high, medium and low frequency signals balancedly, without any modification, rendering but faithfully reproduced the audio signals for playback

6. It has 50Hz to 40KHz ultra-linear frequency response.

7. With balanced XLR and unbalanced Phone type input pors.

8.Low frequency adjustment: four band switch for -3dB,-1.5dB decrease and +1.5dB increase; High frequency adjustment: three band switch for -1.5dB decrease and +1.5dB increase.

9. Linear wave radiator design greatly improve the cooling effect.

10. With high hardness wear-resistant coating on thick wooden box shell.

Model No.		MS500	MS650
Description		Two-way active loudspeaker	Two-way active loudspeaker
Crossover point		2.5KHz LF:24dB/OCT,HF:24dB/OCT	2.5KHz LF:24dB/OCT,HF:24dB/OCT
Frequency response		50HZ-40KHz(-10dB)	50HZ-40KHz(-10dB)
SPL		101dB,1M ON AXIS	106dB,1M ON AXIS
Production Dimension(mm)		180235300	210240325
Packing Dimension(mm)		250310380	280310410
N.W.(KG)		7.3	8.2
G.W.(KG)		8.8	9.7
Shield		Yes	Yes
Component		5"Low+1"Hi	6.5"Low+1"Hi
Construction material		MDF	MDF
Output power		LF:42W THD=0.01%,RL=4Ω	LF:80W THD=0.03%,RL=4Ω
Output power		HF=28W THD=0.02% RL=8Ω	HF=50W THD=0.03% RL=8Ω
S/N ratio		≥94dB GAIN=MAX	≥94dB GAIN=MAX
Sensitivity	XLR input	+4dB GAIN=CENTER	+4dB GAIN=CENTER
	XLR input	-6dB GAIN=MAX	-6dB GAIN=MAX
	6.35 input	-10dB GAIN=CENTER	-10dB GAIN=CENTER
	6.35 input	-20dB GAIN=MAX	-20dB GAIN=MAX
Input type& impedance	XLR input	XLR balanced 10KΩ	XLR input balanced 10KΩ
Input type& impedance	6.35 input	6.35 input unbalanced 10KΩ	6.35 input unbalanced 10KΩ
AES input frequency specification		32KHZ-192KHz,16bit-24bit	32KHZ-192KHz,16bit-24bit
AES sensitivity		-20dBFS GAIN=MAX	-20dBFS GAIN=MAX
AES input output impedance		110 Ohms	110 Ohms
AES minimum input signal		50%T 200MV	50%T 200MV
Gain adjustment		31bit adjust	31 bit adjust
EQ switch	High frequency	+1.5/0/-1.5dB 15KHz	+1.5/0/-1.5dB 15KHz
EQ switch	Low frequency	+1.5/0/-1.5/-3dB 60Hz	+1.5/0/-1.5/-3dB 60Hz
Power switch		ON/OFF	ON/OFF
LED indicator		Green:power is on	Green:power is on
LED indicator		Red:signal clipping	Red:signal clipping
Power		60W	100W
Input voltage		AC 200V-240V/50Hz	AC 200V-240V/50Hz
