24v Power Supply 400w

Name: 24v Power Supply 400w
Brand: zoyea
SKU: 115105403

US$ 14.38 - 15 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

zoyea

Model Number:

S-400w

Shenzhen Zoyea LED Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name zoyea

Model Number S-400w

Output Power 401 - 500W

Output Type Single

Input Voltage 110V

Output Voltage 12v

Output Frequency 47-63HZ

Output Current 33.3A

Specifications

24v power supply 400w
1.100% load test.
2.CE&ROHS
3.Efficiency 85%
4.Quality assurance year

24v power supply 400w

Product Electric Parameters
Input specification	Input voltage			AC220V /±10%
	Input frequency			50Hz
	Input surge			20A@120VAC40A@230VAC
Output specification	Output voltage can be adjusted			±10%
	Start-up time			<1S(input230V,Io=100%)
	keep time			>20mS (input230V,Io=100%)
	Voltage regulation			(Full load) <0.5%
Protection function	Overload protection			105% - 150% rated power, automatic recovery
	Over-voltage protection			105% - 150% of the rated voltage
Insulation intensity	Input---output			1500VAC/1min
	Input---ground			1500VAC/1min
	Input---ground			500VAC/1min
Safety standards	According with GB4943, UL60950-1,EN60950-1 standards.
E M C standards	According with GB9254, EN55022 class A EN61347-2-13:2008 standards
Environmental	working temperature			- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature			- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level			<2000M
Structure	Size(mm)			260(L)102(W)65(H)
Cooling method	Cooling method			Through the fan make temperature decrease
Weight	1.1KG/PCS
Product Type Table
Product model		output specification			ripple, noise	efficiency
S-400-9		9V	44A		70mV	78%
S-400-12		12V	33A		100mV	80%
S-400-15		15V	27A		100mV	80%
S-400-24		24V	17A		100mV	80%
S-400-28		28V	14.5A		100mV	80%
S-400-36		36V	11.5A		120mV	80%
S-400-48		48V	8.5A		240mV	82%
