China Profect and Low Price Well Vertical Boring Machine BC10A of Almaco Company

China Profect and Low Price Well Vertical Boring Machine BC10A of Almaco Company thumbnail-1
China Profect and Low Price Well Vertical Boring Machine BC10A of Almaco Company photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Almaco Machine Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai.china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Place of Origin Jiangsu, China
Brand Name ALMACO
Model Number BC10A
Voltage 380V
Dimension(L*W*H) 1700*1550*1900mm
Weight 2000/2500kg
Certification CE;ISO



china profect and low price well vertical boring machine BC10A of almaco company



Product Description

vertical boring machine BC10A



Features:

1,The table longitudinally and latitudinally moving device.

2,The working fast centering device.

3,Boring measuring device.

4,Also provides optional digital read out for the tables moving.









Data

vertical boring machine BC10A

1, Universal spindle 2, Boring spindle 110
3, Boring spindle 75 4, Boring spindle 56
5, Boring spindle 45 6, Tool Box
7, V-type cylinder fixture 8, Quick cylinder fixture
9, Boring measuring device 10, Boring spindle 150
11, Universal boring & milling head 12,4#boring bar





 ♥Standard accessories           ♣Oprional accessorise
   1  2  3  4  5  6  7 8 9 10 11 12 13
BC16A   ♣       ♥      ♣     ♣     ♥        ♣
BC10B      ♣       ♥      ♣      ♣     ♥         ♥
BC20B      ♣       ♣      ♣      ♣      ♣     ♥     ♣      ♣     ♥    ♥  ♥
BC20C     ♥      ♣      ♣      ♣      ♣     ♥     ♣      ♣      ♥   ♥     ♥     ♥
BC20D     ♥         ♣      ♣      ♣      ♣     ♥     ♣        ♣      ♥   ♥     ♥     ♥



    14501 14502 14503 14504 14505
Modle BC20B BC10A BC16A BC20D BC20C
Max.Boring dia. mm 200 100 165 200 200
Max.Boring depth mm 500 325 410 500 500
Spindle speed steps   9 9 9 250 250
Spindle speed range mm/rev 53-840 65-100 190-600 53-840 53-840
Spindle feed steps  mm 4 4 4 9 9
Spindle feed range mm 0.05-0.2 0.05-0.2 0.05-0.2 0.05-0.2 0.05-0.2
Spindle travel mm 710 410 550 710

710
Distance from spindle certerline to the vertical side on the slide mm 315 390 315 315 315
Table dimension mm 500*1250 400*1000 500*1200 500*1250 500*1250
Longitudinal travel mm 900 650 700 100 100
Cross travel  mm 100 100   160 160
Machine accuracy Accuracy   IT7 IT7 IT7 IT7/IT8 IT7/IT8
Roundness mm 0.0025 0.002 0.0025 0.005 0.005
Cylindricity mm 0.01/300 0.01/300 0.01/300 0.01/300 0.01/300
Surfuce roughness mm Ra0.8 Ra0.8 Ra0.8 Ra0.8 Ra0.8
Overrall dimensions mm 1580*1250*2340 1700*1550*1990 1860*1550*2230 1588*2610*2350 1588*2610*2350
N.W/G.W. Kg 3300/3800 2000/2500 2500/3000 3500 3500











Product show

vertical boring machine BC10A

china profect and low price well vertical boring machine BC10A of almaco company





our factory

china profect and low price well vertical boring machine BC10A of almaco company



engineer team



Advantages

Our advantage:

1,More then 20 years experience for indusry product

2,All modles with CE,TUV,SGS,ISO9001/9002 or other authority approved

3,Professional service and technology

4,Excellent reputation all over the world

5,Final exported producuts would pass strict test by international authority BIVAC

6, There is more exporting experience for 20years with our owned manufacture/company



Packaging & Shipping

china profect and low price well vertical boring machine BC10A of almaco company



Company Information

Welcome to Almaco Machine Tool Co., Ltd



our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.



We are looking forward to bulding sincere and long-term business relationship with you



china profect and low price well vertical boring machine BC10A of almaco company

china profect and low price well vertical boring machine BC10A of almaco company
