cnc lathe with low price
1. H36 cnc lathe with low price specification
cnc lathe with low price |
Unit |
H36 |
Max. swing over bed |
mm |
Φ360 |
Max. sing over cross slide |
mm |
Φ110 |
Max. processing length |
mm |
250 |
Chuck |
inch |
6″ optional |
X axis travel |
mm |
340 |
Z axis travel |
mm |
250 |
Guide way |
|
Taiwan brand HIWIN linear guide |
Spindle unit speed |
rpm |
2500 /4000 |
Spindle nose |
|
A2-5 |
Thro-hole diameter of spindle |
mm |
Φ48 |
Spindle drawing bar diamter |
mm |
Φ38 |
Rapid feed speed |
m/min |
X:15 Z:15 |
Spindle motor power |
kw |
4 |
X/Z motor power |
kw |
1/1.5 |
X/Z motor torque |
N.m |
4/4 |
Tool bar section |
mm |
20×20 |
Tool post type |
pcs |
4-station gang type tool post |
Optional |
|
4-station electric turret |
X/Z position accuracy |
mm |
0.016/0.02 |
X/Z repeatability |
mm |
0.006/0.006 |
Machine dimension (L*W*H) |
mm |
2000×1400×1580 |
N.W. |
KG |
1500 |
2.Standard accessories of H36 cnc lathe with low price
GSK980TDC or Siemens 808d NC system
invertor motor 4kw
4 station gang type tool post
spring collet
automatic integrated lubrication system
coolant system
lighten system
3.Optional accessories of H36 cnc lathe with low price
KND 1000Ti, Fanuc 0I MATE TD NC system
servo motor 3.7/5.5 kw
inverter 5.5 kw
4 station electric turret
6″Non-through hole hydraulic chuck
6″through hole hydraulic chuck
6″Non-through hole hydraulic chuck (Taiwan)
6″through hole hydraulic chuck(Taiwan)
H36 cnc lathe with low price
