Help CenterCH1460 Chinese Bench Lathe Machine
Related Products
bench lathe machine tool
1. Features of CH1460 bench lathe machine tool
Bed rail is VHF hardening and precision grinding , higher rigidity and higher precision.
Spindle speed 12 steps .
Main motor larger power 2.2kW (3HP)
Foot pedal breaker could brake lathe quickly
Emergency stop button, very safe.
Jog spindle rotation is easy to change speed steps or unloading work-pieces
Safe switch automatically cuts off the power supply when transform belt or hanging gear.
2. Bench lathe specification CH1460
capacity |
machine model |
bench lathe CH1460 |
|
Swing over bed |
356mm |
|
Swing over cross slide |
210mm |
|
Max.swing over gap |
508 mm |
|
Effective length of gap |
180 mm |
|
Center Distance |
1500 mm |
|
Bed Width |
260 mm |
head stock |
Spindle hole |
40 mm |
|
Spindle nose |
ISO-4D |
|
Spindle taper |
MT5# |
|
Spindle speed(Number) |
(12steps)40-1800rpm |
feeds |
Longitudinal feeds range |
37kinds 0.043-0.653mm/rev |
|
Cross feeds range |
37kinds 0.024-0.359mm/rev |
|
Metric threads range |
37kinds 0.4-7mm |
|
Inch threads range |
28kinds 4-56inch |
main screw |
Dia. of main screw |
22mm |
|
Pitch of main screw |
4mm or 8T.P.I |
tailstock |
Dia.of tailstock sleeve |
45mm |
|
Taper of tailstock sleeve |
MT3 |
|
Max.travel of tailstock |
120mm |
motor |
Main drive motor |
2.2KW |
|
Coolant pump motor |
40W |
dimension |
1500mm CH1460 |
245*75*150cm |
weight |
1500mm CH1460 |
1350/1650kg |
3.Our service and delivery
1. engineers are available to do oversea machinery service. In some countries, we have oversea agent doing after-sale
service in time and professionally.
2.24 hours heart to heart service on-line or mobile.
3. training in our factory and on-line are free of cost.
4. warranty is 12 months, small broken parts are free of cost to replace, spare parts are delivered with machine for
customer convenience.
5.We offer best agent price and distributer price.
4.Customer and delivery
accept ODM, OEM,
accept FOB, CFR, CIF, EXW price,
T/T 30% as deposit and the balance before machine tools leave our factory.
normal type products with standard configuration manufacturing time is 7-15 working days.
Click " send " now and learn more about our prodcuts.
