Made in China pin barrel cold feed silicone rubber extruder machine
Usage:
The machine is used for extrusion of various rubber porducts and rubber feeding
Structural:
1 Pin-barrel cold feed rubber extruders are made by the Company with introduced technologies. Different extrusion heads are applied to extrude various half-finished rubber products.The machines can also be used to feed fubber to mangiers.
2 The barrel is composed of several zones. In the feeding zone, the spiral slots work with the side rolls to enhance feeding capability. In the plastication and extrusion zones, different numbers of pons are fitted.
3.The screw is processed and polished with the foreign-made milling machine and is featured by excellent geometric precision. Nitrogenation treatment makes it more wear-resistant.
4.The gears in the reducer are made of alloyed steel, whose teeth are hard.
5.A hot water circulation device automatically controls temperature in each zone.
6.The machine is driven by a DC motor.
7.The advantages of the machine include better plastication result, higher extrusion capability, lower temperature of the outgoing rubber and smooth operation.
8.We also make special feeding unit for the pin-barrel cold feed rubber extruder to convey rubber slabs.
Technical specifications:
Data / Model |
XJD- 90X14D |
XJD- 65X12D |
|
Diameter Of screw(mm) |
90 |
65 |
|
L/D |
14:1 |
12:1 |
|
Max. speed of screw(r/min) |
60 |
70 |
|
Size of feeding hopper (LxW) (mm) |
120x80 |
x |
|
Row quantity of pins |
8 |
8 |
|
Pin quantity per row |
6 |
6 |
|
Hot water circulating zones |
3 |
2 |
|
Total power for hot water heating |
24 |
22 |
|
Max output Capacity (kg/h) |
360 |
100 |
|
Motor power (kw) |
55 |
30 |
|
Overall dimension(mm) |
L |
2300 |
1600 |
W |
950 |
1200 |
|
H |
1450 |
1100 |
|
Weight(kg) |
3850 |
2900 |
|
If you are interested in our more products, please check our website:
https://img13.fr-trading.com
Thank you
