Help CenterTransient Voltage Surge Suppression
Related Products
Specifications
transient voltage surge suppression1. 60-100KA
2. 4 pole, three phase, 380V
3. width 36mm for 1 pole
transient voltage surge suppression
· DGM-type surge protector(hereinafter referred to as SPD)adapted to AC,mainly used for rated voltage not exceeding 1000V(RMS),200/380V,50/60Hz power supply system,not exceeding 1500V DC voltage of the circuit and equipment of the Surge Protection.SPD has a phase to phase(L-L),phase to ground(L-NE),phase to neutral(L-N),neutral to ground(N-PE) and combinations such as protected model.
· DGM-based high quality surge protector to use non-linear components and low residual voltage,small discharge current,modulus,and using safely and reliablely,designed and manufactured in accordance with the standards GB18802.1-2002/IEC61643.1,products have passed CE Certification and the national test Room:Beijing Lightning Experimental Device Type Detection Centers.
The DGM-B60/4 exact technology parameter is as below:
Type No. |
DC Power voltage |
Continuous Voltage Uc(V~) |
Standard Discharge Current In(KA) |
Max Discharge Current Imax(KA) |
Protection Level(KA~) |
|
DGM-B60/4 |
220/380
|
275/320 385/420
|
60 |
100 |
2.8KV |
|
