Specifications
Long service life and low noiseDie and roller have long service life
Poultry feed pellet press machine
we are a manufacturer & supplier of feed machines and complete plants founded in 2003.
we have passed ISO9001:2000 international quality standard.
welcome to visit our factory in china ,
or check our products on website.
All of our products are made to customers' request.
Illustrated catalogues are available.
Product Features:
1. High quality direct-gear drive systems are well-known for the trouble-free operation and extremely long working life. Energy transfer is most efficient, about 20% higher than belt driving system.
2. Full stainless steel feeder; Variable-pitch anti-arch structure; Imported frequency converter control.
3. High procision of driving main gear and pinion shaft adopt the carbonizing quenching and hard tooth surface polishing technology, resulting in smooth driving, low noice and long service life.
4. Material of gear box and high precision of driving holes also come from the guarantee of casting technology and experience of specialized casting factory and advanced numerical control equipment.
5. Bearings and oil seals of main driving system are well-known high quality bearing and oil seal such as SKF and etc. And a lubrication oil-return system is especially available to the reliable lubrication of bearing.
Main Technique Data:
Model |
Capacity(t/h) |
Main Power(Kw) |
Power of conditioner (Kw) |
Power of feeder (Kw) |
Inner Diameter of Die (mm) |
Pellet Size(mm) |
FCPM320 |
1-2 |
37 |
2.2 |
0.75 |
¢320 |
¢1.2-18 |
FCPM350 |
2-6 |
55 |
2.2/3 |
0.75 |
¢350 |
¢1.2-18 |
FCPM400 |
4-9 |
75/90 |
5.5/7.5 |
1.5 |
¢400 |
¢1.2-18 |
FCPM420 |
5-11 |
90/110 |
5.5/7.5 |
1.5 |
¢420 |
¢1.2-18 |
FCPM508 |
7-14 |
110/132/160 |
7.5/11 |
1.5 |
¢508 |
¢1.2-18 |
FCPM520 |
8-17 |
110/132/160 |
7.5/11 |
1.5 |
¢508 |
¢1.2-18 |
FCPM580 |
10-22 |
132/160/185 |
7.5/11 |
1.5 |
¢572 |
¢1.2-18 |
FCPM680 |
12-27 |
200/220/250 |
11/15 |
2.2 |
¢673 |
¢1.2-18 |
FCPM780 |
15-35 |
220/250/285 |
15 |
2.2 |
¢772 |
¢1.2-18 |
Our Machine:
Our factory:
Our Location:
FAQ:
1.Q:Are you a factory or trading company?
A:We are a factory .
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Liyang City, Jiangsu Province, China, about 1 hour car from Nanjing .
All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you illustrated catalogues.
