Flexible Solar Panel 200w Mono Solar Panel
US$ 145.5 - 158
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Megasolar
Model Number:
MS-SPM-200
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
dc Lighting System 10kw Home Solar Power SystemUS$ 50 - 500MOQ: 10 Units -
600W AC Output 110V-220V Electric Transformer Portable Solar Power Generator for Laptop/mobile Phone ChargerUS$ 750 - 799MOQ: 5 Pieces
-
Lithium Ion Battery 5000W 220V Portable Solar Power Generator for Home UseUS$ 1 - 365MOQ: 100 Pieces
-
Solar Air to Water Generator With Lithium-ion BatteryUS$ 1 - 690MOQ: 100 Pieces
-
Folded Solar Panel Bag Folding Solar Power Panel Solar Charger Solar Energy System For Notebook/LaptopUS$ 1 - 55MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Megasolar
Model Number
MS-SPM-200
Material
Monocrystalline Silicon
Size
1580*808*35mm
Number of Cells
36
Max. Power
100W-300W
Specifications
1. Wattage: 200W2. Style: mono solar panel
3. Efficiency: 18%
4. Certification: CQC, TUV, CE, ROHS, FCC, PSE
flexible solar panel 200w mono solar panel
Parameters:
| Parameters | MS-SPM-200W-36 |
| Peak Power Pm (W) | 200±3% |
| Open Circuit Voltage Voc (V) | 44.5 |
| Max. Power Voltage Vmp (V) | 36.5 |
| Max. Power Current Imp (A) | 5.48 |
| Short Circuit Current Isc (A) | 5.81 |
| Solar Cells Efficiency | 18.3% |
| Dimensions (L*W*T) / Weight (Kgs) | 1580*808*35mm / 16.0Kgs |
| Solar Cell / No. of cells and connections | Mono crystalline silicon 125*125*0.19mm / 72 series |
| Front Cover (material / thickness) | Low-iron temperd glass / 3.2mm |
| Encapsulant (material) | Ethylene vinyl acetate (EVA) |
| Frame (material / collor) | Anodized aluminum alloy / silver |
| Junction Box Protection Degree | ≥IP65 |
| Cable / Cable Connector Model | PV1-F 1×4.0mm2×900mm / MC4 |
| STC | Irradiance:1000W/m2, Cell temperature:25℃, AM:1.5 |
| Max. Static Load, Front (e. g ., snow / wind) | 2400Pa |
| Max. Static Load, Back (e. g ., wind) | 2400Pa |
| Max. Hailstone Impact (diameter / velocity) | 25mm / 23m/s |
| Max. Over-current (A) | 12A |
| Max. System Voltage (V) | 1000V DC |
| Application Class | Class A |
| NOCT | 48±2℃ |
| Operating Temperature Limits | -40℃- +85℃ |
| Coefficient Current TK | 0.1%/℃ |
| Coefficient Voltage TK | -0.37%/℃ |
| Coefficient Power TK | -0.45%/℃ |
| Life | ≥25 years |
| Warranty | 10-year full warranty, 10-year guarantee 90% of rated power, 25-year guarantee 80% of rated power |
| Product Certification / Standard | CQC, TUV, CE, ROHS, FCC, PSE / (IEC61215&IEC61730) |
| Other Certification | ISO 9001:2008 |
flexible solar panel 200w mono solar panel
