Help Center8" TH180 DTH Hammer
Related Products
-
12" TH275 DTH HammerNegotiableMOQ: 1 Set -
TS18 DTH Hammer for Deep Hole DrillingUS$ 35,000 - 40,000MOQ: 1 Set
-
DTH TS18 DTH Hammer for Oil and Gas Deep Hole DrillingUS$ 35,000 - 40,000MOQ: 1 Set
-
14"TS330 DTH Hammer for Oil,deep Hole DrillingUS$ 17,500 - 20,000MOQ: 1 Set
-
10" TH10 DTH HammerUS$ 5,500 - 6,000MOQ: 1 Set
Specifications
TH180 DTH hammer:Valveless hammerMaterial:alloy stee
Processing type:Forging
Best heat treatment
Long service life
Matched products: 89mm drill rods with API 4 1/2"REG BOX
bits with COP84.DHD380,Mission80,QL80,SD8 shanks
Application fields: all kinds of fields, such as mining, quarry, tunnel, bridge, construction and etc., but extremely exellent to use with casing tubes during casing drilling.
Features:high impact power with low frequency, long service life, non-return flushing, reliable performance.
Techincal Parameters
|
Description |
Product Code |
Bit Shank |
Thread Connection |
Outer Dia. (mm) |
Length Without Bit (mm) |
Weight (kg) |
Flat Wrench (mm) |
Rec. Hole Size (mm) |
||
TH180 |
260000 |
DHD380 COP84 |
API 4 1/2" REG PIN |
180 |
1522 |
190 |
150 |
203-271 |
||
|
Working Pressure (bar) |
Impact Frequency at 17 bar (Hz) |
Normal Axial Pressure (kN) |
Rec. Rotation Speed (r/min) |
Air Consumption (m³/min) |
||||||
14-24 |
20 |
18.3 |
30-40 |
12bar |
17bar |
24bar |
||||
| 22.5 | 28.2 | 39.6 |
||||||||
|
Hammers Matching To Other Bits | ||||||||
Description |
Product Code |
Bit Shank |
Thread Connection |
Outer Dia. (mm) |
Length Without Bit (mm) |
Weight (kg) |
Flat Wrench (mm) |
Rec. Hole Size (mm) |
TH180-QL80 |
260001 |
QL80 |
API 4 1/2" REG PIN |
180 |
1515 |
190 |
150 |
203-271 |
TH180-Mission80 |
260003 |
Mission80 |
1515 |
188 |
||||
TH180-MACH80 |
260005 |
MACH80 |
1522 |
190 |
||||
TH180-SD8 |
261000 |
SD8 |
1492 |
195 |
||||
|
Working Pressure (bar) |
Impact Frequency at 17 bar |
Normal Axial Pressure (kN) |
Rec. Rotation Speed (r/min) |
Air Consumption (m³/min) |
14-24 |
20 |
18.3 |
30-40 |
14bar 22.5 |
17bar 28.2 |
24bar 39.6 |
Photos:
