TS180 DTH Hammer

TS180 DTH Hammer thumbnail-1
TS180 DTH Hammer photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Tianhe
Model Number:
TS180 DTH hammer
Contact Supplier Request Quote Chat Now
Changsha Tianhe Drilling Tools And Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name Tianhe
Model Number TS180 DTH hammer
Type Other, DTH hammer
Material Other, carbides, Carbide
Use Other, oil and gas exploitation

Specifications

TS180 DTH hammer:
Certificate: ISO9001:2008, SONCAP
Material: Carbide
Long service life
Processing type:Forging

Usage: drilling holes from 203mm to 271mm

Application Range: To drill deep holes for oil and gas exploitation,water well, and other projects boring holes with depth 300 meters above and diameters 216mm above.

Design Principles:Mostly increase the reliability of drilling tools to overcome difficulties caused by underground complications.

Features:Reliable performance
Easy to disassemble and assemble

Technical Parameter:


Description


Product Code


Bit Shank


Thread Connection


Outside



Dia. (mm)


Length Without

Bit

(mm)


Weight

(kg)


Flat

Wrench

(mm)


Rec. Hole

Size

(mm)

TS180

264000

TS180

API 4 1/2" REG PIN

180

1551

195

150

203-271


Working Pressure (bar)

17ba

Impact Frequency at 17 bar(Hz)


Normal Axial Pressure(kN)


Recommended Rotation Speed(r/min)


Air Consumption(m³/min)

14-24

20

18.3

30-40

14bar

21bar

24bar

22.5

28.2

39.6

























TS180 DTH Hammer
