Heat resistant glass
I. Specification of Product
1)Dimensions: 1150mm×850mm 1150mm×1700mm 1200mm×600mm other formats upon request
2)Available thickness: 1mm--12mm
List of Thickness and Tolerance
Thickness mm |
Tolerance mm |
Thickness mm |
Tolerance mm |
1.50 |
±0.20 |
4.00 |
±0.15 |
2.00 |
±0.20 |
5.00 |
±0.15 |
2.25 |
±0.20 |
5.50 |
±0.15 |
2.75 |
±0.20 |
6.00 |
±0.15 |
3.0 |
±0.20 |
6.50 |
±0.20 |
3.30 |
±0.20 |
7.50 |
±0.30 |
3.80 |
±0.15 |
8.00 |
±0.30 |
3) Net sized glass of strengthening can be supplied as per the customers requirement;
4) Glass of small cut size is available according the requirement from customers.
II. Performance of the Product
1). Mechanical Performance
Density 2.23±0.02g/cm3
2).Thermodynamic Performance
Thermal expansion coefficient (0-300) 3.3±0.1×10-6K-1
Softening point 820±10
Strain point 516±10
Caloricity (20-100) 0.82KJ × (kg×K)-1
Thermal coefficient 1.2W×m×K-1
Thermal shock resistance 180K
Strengthening type 300K
Identical temperature difference 100K
Strengthening type 300 K
Maximum working temperature Short time(<10h): 500
Long time(>10h): 450
