Specifications
WenZhou variable ac power supply1.IEC CE ROSH SAA CK BV certificated
2. Over voltage Over heat protection
WenZhou variable ac power supply
Welcome,my friend!
Glad to introduce CHMS-25-12 Switching power supply and our company to you. If you have any questions, please don't hesitate to ask me.
Product details
Feature
| 1.Cooling by free air convection. |
| 2. AC input power suitable for the world. |
| 3. Low price and high reliability. |
| 4.Low output ripple and noise. |
| 5. With short circuit and overload protection. |
| 6. Compact size, light weight. |
WenZhou variable ac power supply
Technology parameter
| Model | CHMS25-5 | CHMS25-12 | CHMS25-24 | CHMS25-48 |
| Voltage, frequency | 170-260VAC,47-63Hz;240-370VDC | |||
| Current | 0.17A/230V | |||
| Efficiency (AC220V) | 75% | 77% | 77% | 78% |
| Inrush current | 23A/230V at cold start | |||
| Voltage | 5V | 12V | 24V | 48V |
| Current | 5A | 2.1A | 1A | 0.5A |
| Regulation line | 1% | 1% | 1% | 1% |
| Regulation load | 3% | 1% | 0.50% | 0.50% |
| Ripple noise | ≤50mVp-p | ≤60mVp-p | ≤150mVp-p | ≤300mVp-p |
| Temperature Drift | ±0.03%/°C(0-50°C) | |||
| DC output wattage | 25W | 25W | 24W | 24W |
| Rise,&hold time | 1s,100ms,50ms | |||
| Over current protection | 105%-150% works at over 105%-120% of rating and recovers automatically | |||
| Over voltage protection | / | |||
| Over heat protection | / | |||
| Input to output | AC1500V;500VDC/100MΩ | |||
| Input-case,FG | AC1500V;500VDC/100MΩ | |||
| Output-case,FG | AC500V;500VDC/100MΩ | |||
| Operating temperature and humidity | -10°C- +60°C,20%-90%RH | |||
| Storage temperature and humidity | -20°C- +85°C,10%-95%RH | |||
| Vibration | 10-500Hz at 2G,10minutes period, 60 minutes along X,Y and Z axis | |||
| Authenticate | IEC CE ROSH SAA CK BV | |||
| EMC standards | IEC/K60950-1 EN61347-1:2008 | |||
