Specifications
pressure switchSuitable for water & gas & air & oil & steam & corrosive & vacuum,
Pressure range: Vacuum -14.5 to 3000PI
gas control pressure switch
Advantages:
fessional skill
2.Specific products
3.Tailored cost-effective production for our customers
Technical Parameter:
1,Switching type : SPST NC or SPST NO or SPDT NC+NO (Selectable),
Switch frequency & Response time: 60 Cycle /min, ≤100ms.
2,Pressure fitting: a variety of user-selectable.
3,Electrical connection: a variety of user-selectable.
4,Voltage: 5VDC to 110VDC, 5VAC to 250VAC;
Resistance load : 0.1A to 6A,
Inductive load : 0.1A to 3A.
5,Fluid media: water & gas & air & oil & steam & corrosive,ect .
6,Work Life: ≥100,000 Cycle.
7,Protection class : IP65.
8,Ambient temperature: -40°C~125°C(Selectable), Medium temperature: -40°C~150°C(Selectable).
9,Model: a variety of user-selectable.
10,Working pressure: Vacuum -14.5PSI to +3000PSI (Selectable).
After-sales service:
We promise to carry out the following after-sales service:
Warranty: The warranty period is 12 months starting from the shipping date.
The rate of Production Quality Problem is lower to 100PPM, replace the bad for free
