3D design drawing Customizable Motor driven Single Beam Overhead Crane
-----------------Best Solutions Ready For Installation To Meet Individual Requirements
1. Reasonable structure, light dead weight
2. Favorable performance, accurate and smooth lifting.
3. Safe and reliable traveling
4. Low noise, easy operation,
5. Convenient maintenance, high exchangeability for parts and components
Crane capacity: 1t~ 32ton
crane working environment temperature: -25 to 40centigrade.
Crane Using:widely used in factory, warehouse, stuff yard to lift goods.
Configuration:
Material: Steel plate material Q235 or Q345B ( similar international steel plate FE3 or FE52)
Steel structure: Strong Steel box type, seamless type, more strong and elegant beam.
Crane traveling motor: Soft start type
Wheel: Inter medium frequency quenching
Main electrical parts: Schneider brand or Siemens brand.
Crane travelling mechanism |
Working speed |
(ground)20 |
(ground)30 |
Room |
||
Speed ratio |
58.78 |
39.38 |
26.36 |
|||
Motor |
Type |
YSE802-4 |
YSE90L-4 |
ZDR100-4 |
||
Power |
2×0.8 |
2×1.5 |
2×1.5 |
|||
Rotational speed |
1380 |
|||||
Lifting mechanism electric hoist travelling mechanism |
Model of electric hoist |
MD1 MODEL |
CD1MODEL |
|||
Lifting speed |
8/0.8(7/0.7) |
8(7) |
||||
Lifting height |
6,9,12,18,24,30 |
|||||
Travelling speed |
20 |
|||||
Motor |
Cone squirrel-cage model |
|||||
Working duty |
A3 |
|||||
Electric current |
As your demand |
|||||
Wheel diameter |
Φ270 |
|||||
Width of trail |
37~70mm |
|||||
Normal Quotations:
1. Lifting capacity ______ton
2. Single beam or double beam?
3. Standard type or Europe type?
4. Crane Span _______meters (Rail middle center to center distance)
5. Lifting height ______meters (Hook to ground)
6. Industrial voltage _____V, _____HZ, 3Phases
7. Control mode
A. Pendant control B. Remote control C. Cabin control
8. What material does the crane lift?
9. Do you also need us to supply bearing beam, rail and slide wire?
A. Yes B. No
10. Any special design demand on crane?
