8 ch ASI -IP Converter/8 Channel Asi- ip Gateway

Name: 8 ch ASI -IP Converter/8 Channel Asi- ip Gateway
Brand: Sochuang
SKU: 116090755

US$ 1 - 800 MOQ: 1 Set

Key Specifications

Place of Origin:

Sichuan, China

Brand Name:

Sochuang

Model Number:

SC-2235

Chengdu Sochuang Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

chengdu

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Sichuan, China

Brand Name Sochuang

Model Number SC-2235

CATV IP Gateway

Overview:

8ASI-8IP Adapter/Gateway is one of the main equipment of the cable digital TV headend,

receiving data from theencoder, multiplexer, DVB gateway, scrambler, video server and other DVB

transport stream, transform into IP/UDPstreams (TS over IP) Multicast, or to receive transport

stream from the network and transform into ASI stream.

Features:

u Full hardware implementation, high efficiency and stability;

u 8ASI-8IP, 8IP-8ASI, Gigabit ts over ip port

u 8MB cache, anti-burst stream;

u Real-time stream monitoring;

u Local and remote control;

u LCD display in Chinese and English, easy and flexible to operate;

u High reliability, stable.

Technical Specification:

Management			Network RJ-45 10/100m base-TX,NMS
Out	ASI		BNC/TS
Out	IP		UDP/RTP, SPTS/Multicast, TS over IP(Gigabit
General Features		Size	44mm482240mm
		Environment	0 ~ 45(Operating); -20 ~ 80(Storage)
		Power	220VAC(-+10%),50Hz,25W
