asi ip spts iptv gateway (8ASI-to-64SPTS IP,multicast,only work with Gigabit port)
8ASI-to-64SPTS IP,multicast
8 MPTS IP/UDP out,ts over ip
8*ASI to SPTS IP Gateway
Overview
8*ASI to SPTS IP Gateway supports 8 ASI input and output SPTS Multicast IP transport stream (TS over UDP). It can convert max 64 programs and is mainly applied to IPTV live broadcast system.
Technical Specification
Input |
BNC Interface |
8*ASI |
Output |
1000BASE-T/Gigabit IP port; Max 64*SPTS multicast TS over IP/UDP(Max 8*SPTS/Multicast per satellite transponder); |
|
Control |
IP remote |
NMS (Ethernet Port, RJ-45), 10/100m base-TX, |
Front panel |
Keyboard + LCD |
|
General Features |
Size |
480mm*410mm *44mm |
Temperature |
0 ~ 45 (Operation); -20 ~ 80 (Storage) |
|
Power |
220VAC (-+10%), 50Hz, 25W |
|
Order Guide
2236 |
ASI*8-IP*SPTS IPTV Gateway(8ASI-to-64SPTS IP, only Gigabit port) |
2235 |
8×ASI in, 8×IP/MPTS/Multicast/Gigabit out |
Network Management Software
Input ASI monitor:
Output SPTS channels setting:
multicast ip/udp spts output setting:
TS OVER UDP (VLC):
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
