4IN1 H.264 HDMI DTMB Modulator(4HDMI in,DTMB out)
4IN1 H.264 HDMI DVB-T(DVB-C)(DTMB) Modulator
Overview
4IN1 H.264 HD DTMB Modulator supports 4×HDMI input and 1×RF DTMB output. It integrates encoder and modulator. After coded and modulated, the input signal can be directly output or mixed output with original TV signal. It suits 1U rack and can be configured by front panel LCD and NMS (network management software).
Technical Specification
Input |
4×HDMI 1.3, support 1080p |
|
Encoding |
Video |
4:2:0 encoding H.264 HP@L4 MP@L3 |
H.264 Adaptive Field Frame (AFF) | ||
H.264 Field-Based (FB) | ||
|
full HD:1920×1080×60/50i/p,1280×720×60p/50p; SD:720*576i(PAL),720*480i(NTSC) | ||
Standard: ISO/IEC14496-10 (H.264/MPEG-4 AVC) | ||
bitrate :1.0~15Mbps continuously adjustable per channel | ||
Audio |
HDMI:embedded audio |
|
Sampling:32KHz, 44.1KHz, 48KHz | ||
Code Rate:64, 128, 192, 256, 384Kbps | ||
DTMB |
Frequency |
30~900MHz, 1KHz step |
Level Attenuation |
0~20dB (0.5dB step) |
|
Interleaving |
240, 720 |
|
Standard |
GB20600-2006 |
|
Constellation |
4 QAM-NR, 4 QAM, 16 QAM, 32 QAM, 64 QAM |
|
Output Level |
85~105dB |
|
Frame Mode |
420 fixed, 595 fixed, 945 fixed, 420 variational, 945 variational |
|
Control |
IP remote |
NMS (Ethernet Port, RJ-45), 10/100m base-TX, |
Front panel |
Keyboard + LCD |
|
General Features |
Size |
482mm×280mm×44mm |
Temperature |
0~45°C (operation); -20~80°C (storage) |
|
Power |
100-240VAC, 50Hz, 25W |
|
Order Guide
4206 |
4IN1 H.264 HDMI encoder DTMB Modulator(4HDMI in,DTMB out) |
4181 |
HD H.264 DTMB modulator(AV/HDMI IN,DTMB RF out) |
Network management software
Output setting:
video,audio setting:
NIT edit (LCN):
Developing :
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
