Beverage Bag Making Machine/spout Inserter

Name: Beverage Bag Making Machine/spout Inserter
Brand: DALAI
SKU: 116106601

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Automatic Grade:

Automatic

Usage:

Other Forming Machine

Nanjing Hengfeng Packaging Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Nanjing

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Automatic Grade Automatic

Usage Other Forming Machine

Place of Origin Jiangsu, China

Brand Name DALAI

Voltage 280v

Power(W) 8kw

Dimension(L*W*H) 5200x2000x1700mm

Weight 2500kg

Specifications

This machine is used to weld stand up spout pouch. It is suitable for packaging juice, jelly, milk ,liquid pets food .

1.Usage
This machine is used to weld stand up spout pouch. It is suitable for packaging juices, jelly, milk,Liquid pets food and Dish washing liquid.

2. Main Technique Features

l Spout fitting and sealing with self-standing pouches and penguin style pouches

l Servo motor drive

l PID temperature control

l Clear display and easy operation

l Plastic pouches lined in the special holding channel for later feeding

l Trouble alarm display and shooting

3. MAIN TECHNICAL SPECIFCATIONS

Pouch pattern	Stand up Pouch, Three Side Seal Pouch, Center Seal Pouch, Side Gusset Pouch, Spout Pouch
Color of machine	White
Pouch size	Width (60~122)mm,Height(60~230)mm Special specifications can be tailor-made
Control mode	PLC+Mechanical transmission
Hot-sealing	Six groups (12pcs)
Compressed air	0.5Mpa. 10L/min
Control system	PLC+Mechanical transmission
Power	380V 50HZ( Special specifications can be tailor-made )
Main motor power	8Kw,Warm-up(20Kw)
Efficiency	1~80Pcs/min
Accuracy	±1mm
Weight	2500Kg
Pouch mode	Single or double group
Dimension of the machine	5200x2000x1700mm

4.ELECTRONIC CONTROL SYSTEM

TEMPERATURE SYSTEM
Temperature mode	PID mode
Control accuracy	1~2°C
Heating system	Warm up and sealing
Heating control	0~300°C
Protection system	Torque protector(2 groups,Italy)

HOT SEALING SYSTEM
