Specifications
1.600V overheard CABLE2.Brand: HFW
3.PVC insulated
4.Rated for use in wet or dry locations
5.600V PVC jacketed
*
600V overheard CABLE
Resistant to oils, lubricants, acids, alkalis, ozone, water and abrasion
* Individual grounds per conductor
* Cabled for flexibility
* Rated for use in wet or dry locations
* 600V PVC jacketed
Conductor 12 AWG Bare Copper
Stranding 19/.0185"
Insulation Material PVC
Insulation Thickness 0.031'' Nom.
Insulated Conductor Diameter 0.151'' Nom.
Ground 16 AWG Bare Copper
Ground Stranding 19/.0117"
Number of Insulated Conductors + Bare Grounds 3 + 3
Lay Length 3.00'' Nom.
Filler Type Polypropylene
Separator Paper Tissue
Jacket Material PVC
Jacket Thickness 0.047'' Nom.
Overall Cable Diameter 0.420'' Nom.
Electrical Properties:
Temperature Rating 60OC
Rated Voltage 600 V
DC Resistance per Conductor @ 20OC 1.62 Ohms/1M' Nom.
Ampacity Per NEC Table 310.16 and
Adjustment Factors per Table 310.15(B)(2)(a)
Insulation Colors Conductors: Black White Red Grounds: Bare copper
Jacket Color Gray
Applications:
* Branches from overhead busways
* Temporary power to stationary industrial equipment
* For use as drop cables from overhead busways as permitted by Article 368.8 of the National Electric Code
* Allows for easy relocation of plant equipment
Our advantage :
1. High Quality , Can offer certificate like CSA/UL/CCC/ROHS/REACH and others certificate as you need.
2. Good Experience , Over 10 Years produce experience ,Work with Huawei Technology and ZTE Corporation ,and others famous company .
3 . Good service ,Accept OEM and ODM service, as produce as your design .
4 Good price , With best material purchase department and high dfficiency produce department.
