Home > Metallurgy, Mineral & Energy > Steel & Products > Stainless Steel > 1.4301 Steel Plate

1.4301 Steel Plate

Name: 1.4301 Steel Plate
Brand: Dongbei Tegang
SKU: 116188563

US$ 2,000 - 4,000 MOQ: 1 Ton

Key Specifications

Get Latest Price

Grade:

300 Series

Standard:

ASTM, AISI, DIN, EN, GB, JIS

Length:

2m-6mm

Contact Supplier Request Quote Chat Now

Sichuan Liaofu Special Steel Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

dalian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Grade 300 Series

Standard ASTM, AISI, DIN, EN, GB, JIS

Length 2m-6mm

Thickness 15mm-800mm

Width 20mm-1000mm

Place of Origin Liaoning, China

Brand Name Dongbei Tegang

Model Number DIN 1.4301

Type Plate

Application Chemical

Certification ISO

ASTM 304/JIS SUS304 Austenitic Stainless Heat resistant Steel

304 stainless steel is a kind of common stainless steel materials, corrosion prevention is better than 200 series stainless steel materials. Resistance to high temperature also is better, generally use temperature limit is less than 650 °C. 304 stainless steel has good corrosion and corrosion resistance and better performance of resistance to intergranular corrosion. For oxidizing acid, obtained in the experiment, the concentration of 65% or less under the boiling temperature of nitric acid, 304 stainless steel has a strong corrosion resistance. To most organic and inorganic acid and alkali solution with good corrosion resistance ability

Standards:ASTM,JIS,GB,EN(DIN,BS,NF) Or Per as clients’ requires.

Product Basic Information:

Material		DIN 1.4301
Chemical Composition		Mechanical Properties(In Quenched & Tempered State)
C	≤0.07	Tensile strength(MPA)	205
Si	<1.00	Yield strength (MPA)	520
Mn	<2.00	Elongation(δ5/%)	40
Cr	-	Reduction in Area (ψ/%)	45
Mo	0.15-0.25	Impact (J)	60
P	≤0.035	Hardness	≤187HB
S	≤0..030
Cu	-
Ni	8.00-1100

2.Product Application Areas:

Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical industry,

electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.

3.Similar steel grade & equivalent steel materials:

USA	Japanese	Gemany	British	France	International	Chinese
ASTM&AISI&SAE	JIS	EN DIN	EN BS	EN NF	ISO	GB
304	SUS304	X5CrNi18-10(1.4301)			------	0Cr18Ni9

High strength and resistance to intergranular corrosion and chloride stress corrosion is improved obviously. Stainless steel has great corrosion performance.

Product Sales Information:

Material	DIN 1.4301 stainless steel
Size	Diameter:20mm-1000mm Length:500mm-6000mm
Origin place	Made In China
Delivery Condition	Hot rolled,cold drawn,forged
Surface require	Black,grinding,bright,polish
Heat treatment	Quenched,Tempered,annealed
Packing	seaworthy packing ,wooden case ,carton,woven bag or at client's requires
Delivery time	In 10-50 days
Trade Term	EXW,FOB,CIF
Payments	T/T or L/C at sight
Port	China main Port,such as shanghai,Dalian,Shenzhen port.
MOQ	1 Ton

Company Main Products:

Alloy Steel	5140,5115,5120,5130,5145,4118,4130,4135,6150,5115,4142,4130,4118,6150,4140,4720,4320 ,E9310,8620,4340
Tool Steel	H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419, SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2
Bearing Steel	GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50
Spring Steel	9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150, SUP10,51CrV4,1.8159
Stainless Steel	321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028, 434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057,201,202,301
