High speed twisted pair cat5e cable
Specification:
1.Conductor: 0.51mm+/-0.01mmBC(bare copper ),CCA,CCS,CCAM
2.Insulation: PE( Polyethylene) minimum thickness of 0.19 mm
3.Conductor diameter :0.91 ± 0.02 mm
4. twisted pairs are covered with PVC jacket (minimum thickness of the shell0.5 mm)
5.The external cable diameter of 5.0 ± 0.2 mm
6. Bending radius: 8xO during installation, 6xO with vertical
7.Shielding:Al-foil+drain wire
8.Operating temperature: -20 ° C - +75 ° C
9.Conductor resistance at 20 ° C :9.38 Om/100 m
10.DC Resistance Unbalance :5%
11.Capacitive unbalance pair to ground :330 pF/100m
12.Impedance 0.772-100 MHz 85-115 Ohm
13.Maximum working capacity of 5.6 nF / m
Electrical Specfications
Dielectric strength |
2.5kv dc-2seconds |
Conductor resistance |
Max 9.38ohm/100mt at 20°C |
Max ring resistance |
16.8ohm/100mt at 20°C |
Max mutual capacitance |
560pf/100mt |
Max capacity unbalance |
330pf/100mt |
Impedance |
100+/-15% at 1~100MHz |
Picture shows:
