3G Terminal/FWT/GatewayBased on W-CDMA
Can connect to PBX.
Support connect with Internet
3G Terminal/FWT/Gateway
Features:
1. Based on W-CDMA
2. Can connect to PBX.
3. Support connect with Internet
4. Can lock SIM card
5. Support Caller ID
6. Making & answering calls after connecting to telephone set.
7. 2RJ-11 ports can support connect with extension
Technique Parameters:
Multimode operation HSUPA/HSDPA/UMTS/EDGE/GPRS/GSM
Triple-band HSPA/UMTS 850/1900/2100 MHz
Quad-band EDGE/GPRS/GSM 850/900/1800/1900 MHz
HSUPA uplink up to 2.0 Mbps
HSDPA downlink up to 7.2 Mbps
WCDMA (UMTS) uplink data rate up to 384 kbps
EDGE data up to 237 Kbps DL and 118Kbps UL, 3GPP Release4, class 12
GPRS data up to 85.6 Kbps DL and 42.8 Kbps UL
Power Supply: DC5 V
Output Power:
Class 3 for UMTS/HSDPA/HSUPA
Class 4 for GSM 900
Class 1 for GSM 1800
Class E2 for EDGE 900/1800
USB: USB 2.0 Full Speed
Antenna Gain >1.5dBm
Environmental Operating Temperature: -10 ~ +55
Storage Temperature: -40 ~ +80
RJ-11 phone interface Dialing tone frequency 450Hz
On hook voltage 45V
Off hook current 30mA/41mA
