China Powder Making Mill Manufacturer,making Powder Mill
US$ 10,000 - 1,000,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Powder Grinding Mill, Pulverizer
Application:
grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earth, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Higher Milling Machine,MTM160 Powder Milling MachineUS$ 110,000 - 120,000MOQ: 1 Set -
Pedestal Grinding Machine,powder Soap Making MachineUS$ 10,000 - 120,000MOQ: 1 Set
-
Professional Supplier of MTM160 Powder Grinding MillUS$ 110,000 - 120,000MOQ: 1 Set
-
Professional Manufacturer of MTM160 Powder Grinding MillUS$ 110,000 - 120,000MOQ: 1 Set
-
Quartz Grinder Mill,US$ 110,000 - 120,000MOQ: 1 Set
Condition
New
Type
Other, Powder Grinding Mill, Pulverizer
Application
grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earth, GCC,CACO3,limestone,zeolite,dolomite,marble,barite and other stones
Motor Type
AC Motor
Power(W)
132000
Capacity(t/h)
20
Place of Origin
Shanghai, China
Brand Name
Dingbo Machinery, Dingbo Machinery
Model Number
MTM160
Dimension(L*W*H)
12550x5700x8350mm
Weight
6.5t
Certification
ISO,CE, ISO,CE
Warranty
2 years
After-sales Service Provided
Engineers available to service machinery overseas
|
MTM160 Mill ,Powder Grinding Mill ,High Pressure Suspension Grinding Mill,Higher,Faster and Stronger Grinder,Grinding Mill
Feldspar Grinder,Calcite Grinding Mill,Bauxite Pulverizer ,Powder Grinding mill,Powder Grinder of High Pressure Suspension Grinding Mill.
Shanghai Dingbo Grinding Mill Description | |||||||
| The grinding processing materials can be grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earths, marble, ceramic, aluminum bauxite, manganese ore, iron ore, copper ore, phosphate rock, red iron oxide, zircon sand, slag, cement clinker, activated carbon, dolomite, granite, garnet, iron oxide yellow, bean cake, chemical fertilizer , compound fertilizer, fly ash, bituminous coal, coke, lignite, Ling U.S. sand, chromium oxide green, gold,fluorspar, bentonite, , thermal insulation, materials in the 9.3 Mohs hardness below 6% moisture in a variety of non-explosive mineral materials processing. | |||||||
| Shanghai Dingbo MTM160 Grinding Mill Features | |||||||
| 1.the Mill grinding roller pressure on the material under the action of the spring in the high-pressure increase 800 - 1200kg. 2.The Mill on the Mohs hardness of less than 9.3 processing of mineral materials can be crushed. 3.The Mill wide range of product particle size, particle size up to 0.613 mm the thickest (30 mesh) particle size of generally up to 0.033 mm (425 mesh), few materials can reach 0.013 mm the smallest (1,000 head). | |||||||
| DBM MTM160 Grinding Mill Technical Parameters List | |||||||
| Item | High Pressure Grinding Mill | ||||||
| Model | MTM160 | ||||||
| Roller(pcs) | 6 | ||||||
| Diameter(mm) | Φ440 | ||||||
| Roller Height(mm) | 270 | ||||||
| Inner Diameter(mm) | 160 | ||||||
| Ring Height(mm) | 270 | ||||||
| Max Input Size(mm) | 35 | ||||||
| Discharging Size(mm) | 0.613-0.033(80Mesh-325mesh) | ||||||
| Capacity(t/h) | 5-20/h | ||||||
| Motor(kw) | 132 | ||||||
| Overall Dimension(mm) | 12550×5700×8350 |
||||||
