| LED lighting at a glance | LED Round Panel Light 18W |
| Installation | Recessed |
| Nominal wattage: | 18W |
| Nominal luminous flux: | 1300lm |
| Comparative value: | approx. 36W fluorescent tube |
| Beam angle: | 120° |
| Dimensions: | ø 223 mm |
| Electrical specification | |
| Operating voltage: | AC 100-240V, 50/60 Hz |
| Rated wattage: | 18 W |
| Power factor: | 0.5 / 0.9 |
| Switching cycles: | > 15.000 |
| Energy efficiency grade: | LED |
| Electrical protection: | IP20 |
| Protection class: | II |
| Lighting specification | |
| Rated luminous flux: | 1300lm |
| Rated color rendering index (CRI): | > 70 / > 80 |
| Rated beam angle: | 120° |
| Rated starting time: | < 0,5 s |
| Rated warm-up time (60 %): | instant full light |
| Further specification | |
| Nominal - / rated lamp life time: | 30.000 h |
| Dimmable: | no |
| Rated lamp mercury content: | 0,0 mg |
| Body housing: | Die-casting Aluminum |
| Operating temperature: | -20 to + 45°C |
LED Slim Panel Light
LED Slim Panel Light in a simple design for uniform omnidirectional light with low power consumption at a relatively high luminosity.
Product Features:
- Ultra slim panel light, available in different standardised sizes, compatiable for replacing.
- Using safe external constant current driver.
- Uniform and well-distrubted light with low power consumption at a relatively high luminosity.
- Replacement to traditional downlight.
- No mercury, UV, IR or flicker.
Comparative value
This 18W LED Panel Light is equivalent to about a 36W fluorescent tube.
Application
The large viewing angle of 120°, this lamp isparticularly suitable for large spaces, where it depends on color-neutraland uniform lighting throughout the room, for example, bathrooms, kitchens, workshops, offices, corridors, staircases, etc.
Never change bulbs!
This lamp contains permanently installed (non-replaceable) LEDs. With a lifetime of 30,000 hours and more than 12,500 cycles it will light years across.
|
Packaging specification |
|
| Packing: | Color Box |
| PCS/CTN: | 30 |
| Carton Box Dimmension (mm): | 470*380*235 |
| CBM/CTN: |
0.0420
|
