Help CenterSolar Garden Fountain (SPB10-401209D)
Related Products
-
Submersible Fountain Pump (SPB20-501210A)US$ 1 - 100MOQ: 1 Set -
Solar Bird Bath (SP1.5-320605-R)US$ 1 - 100MOQ: 1 Set
-
Solar Drip Irrigation Pump (SPB2-320607T)US$ 1 - 100MOQ: 1 Set
-
Solar Pump for Fountain (SP2-320607A)US$ 1 - 100MOQ: 1 Set
-
Solar Powered Water Pump (SP5-401209A)US$ 1 - 100MOQ: 1 Set
•Typical applications include creating garden fountains, pumping water for water features and conducting fish pond filtration and aeration.
•The solar garden fountain kit consists of a DC brushless dry run protected water pump, a solar panel module and a battery backup.
•Solar powered, maintenance free, operation cost free and easy to install with no need for wiring. More importantly, it is much safer for kids thanks to its low working voltage.
•Self-invented unique dry run protection technology prevents the pump from burning out when fountain or pool dries out.
•Locked rotor protection prevents the pump from possible failure when pond debris blocks the pump.
•Brushless motor with no failure-prone carbon brush or shaft seal so that a robust and long service life could be expected.
•Battery back up, runs perfectly on overcast day and in the night.
•Ceramic shaft, runs steadily and quietly.
•Rohs and CE certified, safe and green.
•IP68 waterproof rating on pump thanks to the brushless motor.
•Designed and manufactured to have high power efficiency.
•Cost-effectiveness, competitive price.
Item No. |
SPB10-401209D |
||||||||
Description |
Solar brushless pump kit |
||||||||
Category |
Solar pump kit |
||||||||
| |||||||||
Product Summary | |||||||||
Solar panel |
Solar panel item |
GSP10-36 |
|||||||
Peak power |
10W |
||||||||
Peak power voltage |
17.28V |
||||||||
Peak power current |
0.579A |
||||||||
Pump |
Pump item |
BP401209D |
|||||||
Maximum pump head |
2.0m (6.6ft) |
||||||||
Maximum flow rate |
760L/H (200.8GPH) |
||||||||
Cable length |
5m (16.4ft) |
||||||||
Nozzle item |
NA02 |
||||||||
Battery back-up |
Item No. |
SBB12-4.5 |
|||||||
Battery type |
Lead Acid |
||||||||
Battery capacity |
12V, 4.5Ah |
||||||||
Cable length |
5m (16.4ft) |
||||||||
Flow adjustable |
yes |
||||||||
Dry run protection |
yes |
||||||||
Individual box size |
41.5X27X21cm |
||||||||
Individual box G.W |
6kg |
||||||||
Master carton size |
57X43X24cm |
||||||||
Quantity per carton |
2pcs |
||||||||
Master carton G.W |
13kg |
||||||||
Quantity per 20 container |
954pcs |
||||||||
Quantity per 40 container |
1980pcs |
||||||||
Warranty |
3years |
||||||||
| |||||||||
Litres per hour - At various pumping heights (Head) | |||||||||
Operating |
@ 0m |
@0.5m |
@0.75m |
@1.0m |
@1.5m |
@2.0m |
@2.5m |
@3.0m |
Max height |
12V |
470 |
330 |
75 |
0 |
|
|
|
|
0.9m |
18V |
610 |
450 |
380 |
320 |
50 |
0 |
|
|
1.7m |
24V |
760 |
590 |
540 |
490 |
430 |
0 |
|
|
2.0m |
| |||||||||
Pump Curve | |||||||||
| |||||||||
Overview | |||||||||
|
| |||||||||
