Jiuhong ZLP Sky Climber With Fender Wheels
US$ 1,900 - 6,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
JINFEI TIANHONG
Model Number:
ZLP
Payment & Shipping
Payment Methods:
Port of Shipment:
Tian Jin port china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Construction ZLP Sky Climber/cradle/gondola/window Cleaning MachineUS$ 1,500 - 3,500MOQ: 1 Set -
International Standard ZLP Sky Climber/cradle/gondolaUS$ 1,500 - 3,500MOQ: 1 Set
-
China ZLP Sky Climber/cradle/gondolaUS$ 1,500 - 3,500MOQ: 1 Set
-
China Rope Suspended Platform /gondola/cradle/swing Stage Used for Clean High--buildingsUS$ 2,300 - 3,200MOQ: 1 Unit
-
China Wire Rope Gondola/cradle/swing Stage Used for Clean High--buildingsUS$ 2,700 - 3,600MOQ: 1 Unit
Place of Origin
Beijing, China
Brand Name
JINFEI TIANHONG
Model Number
ZLP
Specifications
sky climber/cradle/gondola1 Avance Tech
2 Stand production line
suspended platform
ZLP800 630Major technique parameter
Name |
Technical parameter |
|||
Rated load |
800Kg |
630Kg |
||
Speed of lifting |
8-10/min |
8-10/min |
||
Length of the platform |
7.5m(2.5m+2.5m+2.5m) |
6m(1m+2m+3m) |
||
wire rope |
Specially-made wire rope A-type 9.1mm(B-type8.6mm) |
Specially-made wire rope 8.3mm |
||
|
Hoist |
Pulling power |
7.84KN |
6.17KN |
|
electric motor |
model |
YEJ100L-4 |
YEJ90L-4 |
|
Power |
A-type 1.8KW( B-type 2.2KW) |
1.5KW |
||
Voltage |
380V |
380V |
||
Rotational speed |
1420rpm |
1420rpm |
||
Braking moment |
15Nm |
15Nm |
||
safety lock |
Permission force of impact |
30KN |
30KN |
|
Locking Cable Angle |
3°~8° |
3°~8° |
||
Packing
