Help CenterFrame of Milling Machine VMC-430(line Rail)
Related Products
-
Frame of Machine SW-DX5050NegotiableMOQ: 1 Set -
Vmc Frame Machine VMC-750(line Rail)NegotiableMOQ: 1 Set
-
Cnc Gold Engraving Machine Frame DX5050NegotiableMOQ: 1 Set
-
the Latest Cnc Engraving Milling Machine Body DX5050NegotiableMOQ: 1 Set
-
Cnc Engraving Machine Body DX5050NegotiableMOQ: 1 Set
welcome to visit our website,the specification data of Fuselage of frame of milling machine VMC-430(line rail) is as followed,if you need other information of our machine,please contact me freely or visit our factory by feild trip.
One. frame of milling machine VMC-430 (line rail) pecifications:
Model |
Table dimension (mm) |
Table T-slot(mm) |
Table load(kg) |
XYZ travel(mm) |
Spindle speed(RPM) |
VMC-430 |
500×320 |
3-14 |
400 |
450×320×350 |
8000 |
Two. frame of milling machine VMC-430 (line rail) Configurations:
1 .Machinery parts of frame of milling machine VMC-430(line rail):
number |
name |
origin |
note |
1 |
spindle |
Taiwan(puson,royal or danquan) |
|
2 |
coupling |
guangda |
|
3 |
Pressure cylinder |
Taiwan(haocheng or shengyu) |
|
4 |
three axis screw |
LTM(taiwan) |
C3 level double nut |
5 |
three axis high precision line rail |
HIWIN(taiwan) |
|
6 |
lubricating oil way |
Nanjing |
Centralized lubrication, with liquid level and pressure alarm |
7 |
bearing |
NSK (Japan) or Nachi (Japan) |
high precision unpaired bearings |
8 |
precision round nut |
YINSH Taiwan |
|
9 |
whole machine screws |
12.9 high strength in Taiwan |
|
10 |
precision lock nut |
YINSH Taiwan |
|
11 |
three axis guide protection |
made in China |
|
12 |
counter weight for Z axis |
made in China |
|
