Help CenterWafer Electric Butterfly Valve EPDM
US$ 130 - 290
MOQ: 10 Sets
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PN10 UPVC Butterfly Valve With Electric ActuatorUS$ 1 - 1,000MOQ: 10 Sets -
Flanged Electric Areation Butterfly Valve With ISO9001NegotiableMOQ: 1 Set
-
Mini Motorized Butterfly ValveUS$ 1 - 500MOQ: 20 Sets
-
Electric Wafer WCB DN20 Butterfly ValveUS$ 1 - 500MOQ: 10 Sets
-
Hard Seal Butterfly ValveUS$ 1 - 1,000MOQ: 10 Pieces
Standard or Nonstandard
Standard
Structure
Butterfly
Pressure
Medium Pressure
Power
Other, Electromotion
Material
Casting
Temperature of Media
Medium Temperature
Media
Water
Port Size
50Nm/60Nm/100Nm
Place of Origin
Zhejiang, China
Model Number
HL -10
Brand Name
HELI
|
Model
|
HL-10 |
||||||||
Power |
DC12V |
DC24V |
DC220V |
AC24V |
AC110V |
AC220V |
AC380V |
||
Motor power |
40W,23W |
||||||||
Rated current |
4.8A |
2.4A |
0.32A |
3A |
0.64A |
0.24A |
0.19A |
||
Output torque |
100Nm |
50Nm/60Nm/100Nm |
|||||||
Action time |
10S |
13S/15S/20S/30S |
|||||||
Circuit control |
B,S,R,H,A,K,D,T |
||||||||
Rotary angle |
0-90° |
||||||||
Weight |
4 Kg |
||||||||
Voltage-with standing value |
500VAC/1min |
1500VAC/1min |
|||||||
Insulated resistance |
100MΩ/300VDC |
100MΩ/500VDC |
|||||||
Protection class |
IP67 |
||||||||
Surrounding Temperature |
-25°C~60°C(The other temperature can be customized) |
||||||||
Installation angle |
Any angle |
||||||||
Case material |
Aluminium die-casting components |
||||||||
Optional function |
Overload protection, heater |
||||||||
