Help CenterHydraulic Bending Mandrel Inside Pipe for Pipeline Bending
Related Products
-
Self-expanding Automatic Pipe MandrelUS$ 40,000 - 50,000MOQ: 1 Unit -
Hydraulic Expandable Bending MandrelUS$ 30,000 - 40,000MOQ: 1 Unit
-
Pneumatic Hydraulic Pipe Bending MandrelUS$ 25,000 - 40,000MOQ: 1 Unit
-
Preheater Worked as Pipeline TorchUS$ 1,000 - 8,000MOQ: 1 Unit
-
Large Diameter Pipe ClampUS$ 4,000 - 70,000MOQ: 1 Unit
Specifications
Mandrel is and important part in pipeline bending,it is for purposes of preventing pipe inner wall from wrinkling,keep ovality1.Introdection of hydraulic bending mandrel
DePing series hydraulic bending mandrel can be powered by hyduaulic or pneumatic,which we can set for you according to specific order.
Mandrel is one of key parts of pipe bending pin, it is for purposes of preventing pipe inner wall from wrinkling and controlling ovality during cold bending process of pipe bending pin.
2.Technical Specifications of hydraulic bending pin
| Model | PBM1618 | PBM2022 | PBM2426 | PBM2830 | PBM3234 |
| Weight | 380KG | 550KG | 620KG | 750KG | 980KG |
| Applicable range | 16"-18" | 20"-22" | 24"-26" | 28"-30" | 32"-34" |
3. More Specifications of hydraulic bending mandrel
3.1.Wedge form force transmission mechanism: powerful and reasonable distributed clamping force,intense self locking function
3.2.Clamping cylinder inside placed:compact and reasonable structure,powerful clamping force.
3.3.Hydraulic motor travelling setting:this setting is for walking function realization,working position can be controlled precisely by the control system.
3.4.Scale polyurethane clamping shoes:reasonable design,easy for assembling and disassembling,high abrasive resistance.
4.More details of hydraulic bending mandrel and Luoyang Deping Technology Co. Ltd.
espiga de curvar
