Bidirectional 860Mhz 1550 Optical Node

US$ 66 - 78 MOQ: 1 Set

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

Model Number:

JZOR860RI-2AIIIm-RDFB2mW

Shaanxi Jizhong Electronics Scien-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen/Ningbo/Tianin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name JZ

Model Number JZOR860RI-2AIIIm-RDFB2mW

Product Introduction:

Extending fiber optic return channel, and user can customize uplink and downlink frequency.
With flexiable RF upgrade function, it can online upgrade downlink frquency to 750/860/1000mhz.
Modular plug-in optical receiving module and 1310nm and 1550nm two window receiving PIN diode, and high sensitivity PIN could receive super-low optical power.
Built-in LED optical power indictor, which precisely disply input optical power.
GaAs amplifier technology, back-level double power amplifer output, high output level.
Excellent AGC function, when input optical power is -7~+2dBm, output level and CTB as well CSO have no change.
Built-in branch splitter and distribution splitter, user could insert branch or distribution slpitter to select output mode.
Output interface feed, 15A overcurrent, each interface has LED indicator.
With Modular structure, reverse transmission platform reserved. The reverse transmission module and duplex filter works once it plugs in.
There are many types of lasers for choose, such as FP, IFP, DFB, which used in different transmission net.
High efficiency switching power supply.
Multi-protection of power supply and effective lightning proof measurements ensures the security.
AL-Diecasting hosing.
With External power supply indicator, easy to maintain.

Main technical parameter:

Item	Unit	Specs		Remark
Forward working bandwidth	MHz	47~1000/862/750		Optional
Input optical power	dBm	-7~+2
Optical wavelength	nm	1200~1600		Two windows
Optical reflection consumption	dB	>45
Equivalent input noise current	PA	≤8
Optical connector		FC/APC or SC/APC
Flatness in band	dB	±0.75
Output reflection consumption	dB	≥16
Link C/N	dB	≥52		79 channel PAL-D analog tv channel,test when input optical power is -1dBm.
Link C/CSO	dB	≥60
Link C/CTB	dB	≥65
Output level	dBμV	≥104
Return working bandwidth	MHz	5~30,5~42 or 5~65		customizable
Return RF input level	dBμV	75~85		Total power
Return output optical power	mW	0.5~4		customizable
NPR	dB	≥15(DFB laser) (NPR≥30dB)	≥10(FP laser) (NPR≥30dB)	customizable
Input voltage	V	B:30~75 A:110~260		AC
Power consumption	W	16
