Boardband Opto-electric Transmission Platform

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

Model Number:

JZOD-6000N

Shaanxi Jizhong Electronics Scien-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen/Ningbo/Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name JZ

Model Number JZOD-6000N

Boardband Opto-electric Transmission Platform

Usage:

It is applied for broadband CATV signal transmission system.

Product Summary

JZOD6000N is a type of broadband photoelectricity transmission platform, with strong versatility, high installing

density, strong function, flexible combination and various telecommunication management modes.

It consists of 13 slots and 19 inches standard rack for fan cooling device.

CMM integrated with VFD status display and operation keys, PS250 series built-in power supply and network management.

Users shall select appreciated module according to fiber networ design request.

There are 10 functional module slots, universl functional module are listed below:

l FTXV1550 optical transmitter module

l EDFA optical amplifier module

l FTX series forward optical transmitting module

l RTX series reverse optical transmitting module

l FRRX series forward optical receiving module

l 4RRX series reverse optical receiving module

l FDA series forward driving amplifying module

l OS series optical switch module

Main technical parameter:

Description	Specification	Notes	Remarks
Frame	4U×19″	4U frame including fan
Power Module	PS-202	AC 220V or DC 48V (alternative)
Optical Transmit Module	OT	Optical transmission power 1~ 20 mW (alternative)	Optical ConnectingType: FC/APC, SC/ APC (alternative)
Forward Optical Receive Module	FOR	Optical receiving power -4 ~ +2dbm, RF output capacity 100 ~ 110 dBμV (alternative)
Reverse Optical Receive Module	ROR	1 or 2 way receiving (alternative)
RF amplifier Module	RF	Input level 70dBμV, output level 100 ~ 108 dBμV (alternative)
NM Responder Module	NMS	RJ45 interface, Ⅱ type net management responder, based on SNMP, TCP/IP protocol, meeting national standard
