Home > Electrical & Electronics > Electric Motor > DC Motor > Bafang 8 Fun 250w Rear Wheel Electric Bicycle Motor
Bafang 8 Fun 250w Rear Wheel Electric Bicycle Motor
US$ 65 - 80
MOQ: 20 Sets
Key Specifications
Get Latest Price
Voltage:
36V
Design:
Brushless
Wattage:
201 - 300w
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
8FUN Bafang High Quality Electric Motor for BicyclesUS$ 80 - 98MOQ: 20 Sets -
8FUN CST Motor Brushless Hub Motor 500wUS$ 80 - 150MOQ: 20 Sets
-
500W Electric Bike Cassette MotorUS$ 90 - 105MOQ: 20 Sets
-
Electric Bike 8fun 500w Motor Bafang Bpm MotorUS$ 80 - 120MOQ: 20 Sets
-
Electric Bike 8fun 250w MotorUS$ 65 - 99MOQ: 20 Sets
Voltage
36V
Design
Brushless
Wattage
201 - 300w
Specifications
electric bicycle motor:1.Voltage:36V
2.Power:250W
3.Bafang SWXH : 25Km/H
PRODUCE NAME: bafang 8 fun 250w rear wheel electric bicycle motor
PRODCUT DESCRIPTION:
Brand: |
Bafang:SWXH2 |
Rated Voltage (V) |
36 |
Rated Power (W) |
250 |
Max Diameter (mm) |
136 |
Max Speed (rpm) |
185-285 |
Rated Efficiency (%) |
≥80% |
Speed(Km/H) |
25-30 |
Wheel size |
20,26,28 inch |
Reduction Ratio |
1:4.3 |
Weight (kg) |
≤3.1 |
Open size (mm) |
135 |
Drive and freewheel type |
6s/7s |
Spoke Specification |
12G,13G |
Cable location |
Shaft center, right |
Hall sensor |
Hall sensor |
Integrate speed sensor |
Optional |
Connector |
optional |
Brake type |
V/Disc (>160) |
Surface |
Silver |
Noise (dB) |
<55 |
Salt fog test (h) |
24/96 |
Water proof Grade |
IP54 |
Certification |
CE ROHS |
This motor can match with our electric bike conversion kit:
