BV 2.5mm Bare Copper Building Wire
US$ 0.001 - 99
MOQ: 6 Kilometers
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Winpower
Model Number:
BV 2.5mm2
Payment & Shipping
Payment Methods:
Port of Shipment:
Port of Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BV 4mm Bare Copper Building WireUS$ 0.001 - 99MOQ: 6 Kilometers -
BVR 4.0MM2 Copper Electrical House WiringUS$ 0.001 - 99MOQ: 6 Kilometers
-
BVR 450V/750V 2.5mm Copper Electrical Building WireUS$ 0.001 - 99MOQ: 6 Kilometers
-
BVR 450V/750V 6.0mm Copper Electrical Wiring in BuildingsUS$ 0.001 - 99MOQ: 6 Kilometers
-
BVR 450V/750V 10.0mm Copper Electrical Wire in BuildingsUS$ 0.001 - 99MOQ: 6 Kilometers
Place of Origin
Jiangsu, China
Brand Name
Winpower
Model Number
BV 2.5mm2
Type
Insulated
Application
Other, Heating, home use
Conductor Material
Copper
Conductor Type
Stranded
Insulation Material
PVC
BV 2.5mm bare copper building wire
Rated temperature: 70 centigrade
Rated voltage:450/750V
Reference standard: JB/T 6213.6-2006
Conductor: solid bare copper wire 49/0.25 mm
Insulation :PVC ,RoHS compliant
Uniform insulation thickness to ensure easy stripping and cutting
Generally it is applied into electrical equipment wire
| conductor | Insulation | Max.COND Resistance |
Dielectric Strength (VAC ,1 MIN) |
|||
|
Cross section (mm2) |
construction no (No./mm) |
dia (mm) |
Thickness (mm) |
O.D. (mm) |
||
| 1.5 | 1/1.38 | 1.13 | 0.70 | 2.40 | 12.1 | 3000 |
| 32/0.20 | 1.31 | 0.70 | 2.60 | 12.1 | 3000 | |
| 2.5 | 1/1.78 | 1.58 | 0.80 | 3.05 | 7.41 | 3000 |
| 49/0.25 | 2.02 | 0.80 | 3.06 | 7.41 | 3000 | |
| 4.0 | 1/2.25 | 2.60 | 0.80 | 4.10 | 4.61 | 3000 |
| 56/0.3 | 3.42 | 0.80 | 4.00 | 4.61 | 3000 | |
| 6.0 | 84/0.30 | 3.42 | 0.80 | 5.20 | 3.08 | 3000 |
| 10.0 | 84/0.40 | 4.56 | 1.00 | 6.30 | 1.83 | 3000 |
| 16.0 | 126/0.40 | 5.60 | 1.00 | 8.0 | 1.15 | 3000 |
