OEM 90W Wire Mesh Oil Filter Making Machine For Gluing , 220V / 50HZ From Filter Machine Manufacturers
US$ 500 - 24,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CHANGJIANG
Model Number:
CJMB-2
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO AND SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Automatic Oil Filter Making Machine / Filter Machinery 20mm - 250mm HeightUS$ 500 - 24,000MOQ: 1 Set -
Filter Caps PVC Gluing / Dispensing Machine Car Oil Filter MachineUS$ 500 - 24,000MOQ: 1 Set
-
Filter End Cap PVC Gluing Pleater Machine Multifunction 60 - 100mmUS$ 500 - 24,000MOQ: 1 Set
-
Steel Bonding Oil Filter Making Machine for Filter Element , 12pcs / MinUS$ 500 - 24,000MOQ: 1 Set
-
High Efficiency Spiral Tube Making Machine Rotary Pleating Machine for Car Oil Filter MachineUS$ 500 - 24,000MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
CHANGJIANG
Model Number
CJMB-2
After-sales Service Provided
Engineers available to service machinery overseas
Detailed Product Description
OEM 90W Wire Mesh Oil Filter Making Machine For Gluing , 220V / 50HZ
Specification
- Production Capacity: 20pcs/min
- Diameter of the Boiled Cap : freely
- Glue Tank Capacity: 15kg
- Working Air Pressure:0.3Mpa
- Power Supply: 220V/50HZ
- Motor Power: 90W
- M/C Weight: 250KG
- M/C Size: 1020*600*700
- Tank Size: 300*1100
Feature
- This machine is light and well built, with precise structure, which is easy to be protected.
- High efficiency with two glue heads.
- New designed head is used which make the sealing function more safe.
- The speed of the main axis can be controlled through variable speed motor to accommodate different working demands.
- Adopts the time relay control, which is operated easily and glued accurately.
Applications
The machine mainly used for gluing the sealed plate of the spin-on filters
