Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > 18kw Yangdong Diesel Generator YSD490D
18kw Yangdong Diesel Generator YSD490D
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
FDK
Model Number:
FYG20
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
30kw Yangdong Diesel Generator YSD490ZLDNegotiableMOQ: 1 Set -
25kw Yangdong Diesel Generator Y4100DNegotiableMOQ: 1 Set
-
IVECO Series Diesel GensetNegotiableMOQ: 1 Set
-
Chinese Brand Yangdong Diesel GeneratorUS$ 2,000 - 10,000MOQ: 1 Set
-
Yangdong Diesel Generator SetUS$ 4,000 - 300,000MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
FDK
Model Number
FYG20
Output Type
AC Three Phase
Speed
1500RPM/1800RPM
Frequency
50HZ/60HZ
Rated Power
20KW
Rated Voltage
230/380V 240/415V
Specifications
yangdong diesel generatorEPA approved
Stamford Alternator
CE, ISO Approval
1year warranty,short delivery
yangdong diesel generator
EPA approved
Stamford Alternator
CE, ISO Approval
1year warranty,short delivery
yangdong diesel generator
Important Features:
Features and Benefits:
*The new and Improved, low speed, liquid-cooled diesel engine.
*Sound-Proof enclosure for a quieter operation.
*Fully automated starting system when used with ATS.
*Optional control panel to help monitor the generator.
*One year/1000 hours limited warranty(whichever is earlier).
*Wide array of system features that can be tailored to your specific application.
| Basic parameter | ||
| Type: | SDG-Y YangDong series | |
| Phase Number | Three Phase | |
| Model: | YSD490D | |
| Rated Frequence(Hz) | 50 | 60 |
| Rated output power(kVA) | 25 | 25 |
| Rated rotation speed(rpm) | 1500 | 1800 |
| DC output | 12V | |
| Power factor cosØ | 0.8 | |
| Noise level(dBA(@)7m)(zero load~full load) | 70 | |
| Structure Type | Slient type | |
| Excitation | Self-excitation and constant voltage(AVR) | |
| Starter system | Electric | |
| Engine model | Y4100G | |
| Engine type | direct injection, water cooled, 4-stroke | |
| Displacement[L(cc)] | 3.298(3298) | |
| Alternator Type | YHG-20 | |
| Fuel tank capacity(L) | 75 | |
| Fuel consumption(g/kw.h) | ≤237 | |
| Continuous running time | 10H | |
| Bore×Stroke [mm(in)] | 100x105 | |
| Displacement[L(cc)] | 3.298 | |
| Shape parameter | ||
| Overall dimension[mm(inch)] | ( 1650 Χ 550 Χ 1150 ) | |
| Dry weight[kg(lbs)] | 850 ( ) | |
| Gross Weight(kg) | 920 | |
