Specifications
1.Easy install;2.OEM is welcome!
3 current can be set as client's need
Product code: HG-WP-PF2270
| Waterproof IP67 for Flood lamp and high bay lamp etc <10W-120W> | ||||||||||
| MODEL | HG-WP2207B | HG-WP2213B | HG-WP2224 | HG-WP2240 | HG-WP-PF2230A | HG-WP-PF2250A | HG-WP-PF2270 | HG-WP-PF22100 | HG-WP-PF22120 | |
| OUTPUT | RATED POWER | 10W | 20W | 30W | 50W | 30W | 50W | 70W | 100W | 120W |
| RATED CURRENT | 300mA | 600mA | 900mA | 1500mA | 900mA | 1500mA | 2100mA | 3000mA | 3600mA | |
| VOLTAGE RANGE | DC25-38V | DC25-38V | DC25-38V | DC25-38V | DC25-38V | DC25-38V | DC25-38V | DC25-38V | DC25-38V | |
| CURRENT TOLERANCE | 5% | |||||||||
| INPUT | VOLTAGE RANGE | AC90-260V | ||||||||
| FREQUENCY RANGE | 47 ~ 63Hz | |||||||||
| POWER FACTOR | >0.5 | >0.5 | >0.5 | >0.5 | >0.95 | >0.95 | >0.95 | >0.95 | >0.95 | |
| EFFICIENCY | 85% | 87% | 87.90% | 87% | 88.70% | 89.50% | 88% | 88% | 88% | |
| ENVIRONMENT | WORKING TEMP | -20 ~ 40°C | -20 ~ 40°C | -20 ~ 40°C | -20 ~ 40°C | -30 ~ 55°C | -30 ~ 55°C | -30 ~ 55°C | -30 ~ 55°C | -30 ~ 55°C |
| QTHERS | DIMENSION (mm) | 71*25*21 | 81*25*21 | 136*30*21 | 108*37*28 | 135*30*25 | 161*32*28 | 154*63*40 | 159*70*45 | 159*70*45 |
Product characteristics:
²Constant current;
²without flicker;
²Low heat,high efficiency;
²Large selection of the parameter, long working-time;
²Using the high frequency low resistance electrolysis with 8000 hours ,excellent quality and stableperformance.
²passing 100% aging test, high reliability;
²With the production of Short circuit,broken circuit,Automatic overload protection
Output characteristics:
Øwatt: 70W
Øvoltage: 25-38V
Øcurrent:2.1A
Øripple:2Vp-p
ØOutput groups:1
Working temperature:-30°C ~ +55°C
Quality guarantee:
üGuarantee:1.The warranty period is 1-2 years.2.During the time ,if the product have any question ,we can change the same to you.
Production process:
Certificate: CE and BV
Custumers feedback:
Application:
OEM is welcome,can be customized !
Cartons
1 how to order ?
A: send me email ,tell me the quantity you need and the method you prefer to send , and i will send you proformer invoice for confirmation , after we recieve the payment , your order will be processing and send to you as agreement with each other .( skype : Tyrone-Soluxled ) .
2 how to pay ?
A : we accept LC ,TT, Paypal , western union ,Ali-pay etc .
