MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA Brake Disc Rotors

MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA Brake Disc Rotors thumbnail-1
MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA Brake Disc Rotors photo-1
US$ 4.65 - 6.52 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Type:
Brake Discs
Material:
Gray cast iron brake disc rotorS
Certification:
ISO9001
Contact Supplier Request Quote Chat Now
Kunshan Chiefting Auto Parts Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Brake Discs
Material Gray cast iron brake disc rotorS
Certification ISO9001
Size 236 mm*41 mm*20 mm
Car Make CHEVROLET/OPEL/DAEWOO
OE NO. 90121445 96574633 90008032 90008006 90511111 569031 569054
Place of Origin Jiangsu, China
Brand Name chiefting brake disc rotors
Model Number opel brake disc rotors
Product Description

A high quality, OE replacement of opel ascona brake disc rotors.This replacement brake disc rotors is made from premium material for optimum disc wear and manufactured to OE replacement design, fit and specifications for balance and reliability.

1, Material:grey cast iron according to HT250(G3000)stardand;

2, Tensile strength:σb≥230N/mm²;

3, Casting hardness: HB180-240;

4, The matrix organization is flaky pearlite and the content is more than 90%;

5, The chemical composition is bellow:

C Si Mn P S Cu Cr A1 C.E
3.10-3.50 1.60-2.10 0.60-1.00 <0.12 <0.12 0.15-0.45 0.05-0.25 <0.012 3.70-4.20

6, 100% crucial dimension inspection;

7, Quality contral:All of opel ascona brake disc rotors are under ISO/TS 16949 quality system certificate;

8, Unbeatable cost effective: compared with others,the same quality,we would have lower price;the same price,we would have better quality;

9, Special Offers: In order to maintain our competitive edge, we are constantly running special offers on our products.Please contact us to see how we can help you save a lot of money.

MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA brake disc rotors

REF NO. of this type

MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA brake disc rotors

Applicable vehicles of opel ascona brake disc rotors:

OPEL  ASCONA C (81_, 86_, 87_, 88_) 1.8 1796 62 4 Saloon 1987-1988
OPEL  ASCONA C (81_, 86_, 87_, 88_) 1.8 E 1796 74 4 Saloon 1985-1986
OPEL  ASCONA C (81_, 86_, 87_, 88_) 1.8 i 1796 85 4 Saloon 1982-1986
OPEL  ASCONA C (81_, 86_, 87_, 88_) 2.0 i 1998 74 4 Saloon 1987-1988
OPEL  ASCONA C (81_, 86_, 87_, 88_) 2.0 i 1998 85 4 Saloon 1986-1988
OPEL  ASCONA C (81_, 86_, 87_, 88_) 2.0 i CAT 1998 85 4 Saloon 1986-1988
OPEL  ASCONA C Hatchback (84_, 89_) 1.8 1796 62 4 Hatchback 1987-1988
OPEL  ASCONA C Hatchback (84_, 89_) 1.8 E 1796 74 4 Hatchback 1985-1986
OPEL  ASCONA C Hatchback (84_, 89_) 1.8 i 1796 85 4 Hatchback 1982-1986
OPEL  ASCONA C Hatchback (84_, 89_) 2.0 i 1998 85 4 Hatchback 1986-1988
OPEL  ASCONA C Hatchback (84_, 89_) 2.0 i CAT 1998 85 4 Hatchback 1986-1988
OPEL  ASTRA F (56_, 57_) 1.4 Si 1389 60 4 Saloon 1992-1998
OPEL  ASTRA F (56_, 57_) 1.4 i 16V 1389 66 4 Saloon 1996-1998
OPEL  ASTRA F (56_, 57_) 1.6 1598 55 4 Saloon 1995-1998
OPEL  ASTRA F (56_, 57_) 1.6 Si 1598 74 4 Saloon 1992-1994
OPEL  ASTRA F (56_, 57_) 1.6 i 1598 52 4 Saloon 1993-1996
OPEL  ASTRA F (56_, 57_) 1.6 i 1598 55 4 Saloon 1992-1998
OPEL  ASTRA F (56_, 57_) 1.6 i 16V 1598 74 4 Saloon 1994-1998
OPEL  ASTRA F (56_, 57_) 1.7 D 1700 42 4 Saloon 1992-1992
OPEL  ASTRA F (56_, 57_) 1.7 D 1700 44 4 Saloon 1992-1998
OPEL  ASTRA F (56_, 57_) 1.7 TDS 1686 60 4 Saloon 1992-1998
OPEL  ASTRA F CLASSIC Estate 1.4 i 1389 44 4 Estate 1998-2005
OPEL  ASTRA F CLASSIC Estate 1.6 i 1598 55 4 Estate 1998-2005
OPEL  ASTRA F CLASSIC Hatchback 1.4 i 1389 44 4 Hatchback 1998-2002
OPEL  ASTRA F CLASSIC Hatchback 1.6 i 1598 55 4 Hatchback 1998-2002
OPEL  ASTRA F CLASSIC Saloon 1.4 i 1389 44 4 Saloon 1998-2002
OPEL  ASTRA F CLASSIC Saloon 1.6 i 1598 55 4 Saloon 1998-2002
OPEL  ASTRA F Convertible (53_B) 1.4 Si 1389 60 4 Convertible 1993-2001
OPEL  ASTRA F Convertible (53_B) 1.4 i 16V 1389 66 4 Convertible 1996-2001
OPEL  ASTRA F Convertible (53_B) 1.6 i 1598 52 4 Convertible 1993-1996
OPEL  ASTRA F Convertible (53_B) 1.6 i 1598 55 4 Convertible 1996-2001
OPEL  ASTRA F Estate (51_, 52_) 1.4 Si 1389 60 4 Estate 1992-1998
OPEL  ASTRA F Estate (51_, 52_) 1.4 i 16V 1389 66 4 Estate 1996-1998
OPEL  ASTRA F Estate (51_, 52_) 1.6 1598 55 4 Estate 1995-1998
OPEL  ASTRA F Estate (51_, 52_) 1.6 Si 1598 74 4 Estate 1992-1994
OPEL  ASTRA F Estate (51_, 52_) 1.6 i 1598 52 4 Estate 1993-1996
OPEL  ASTRA F Estate (51_, 52_) 1.6 i 1598 55 4 Estate 1991-1998
OPEL  ASTRA F Estate (51_, 52_) 1.7 D 1700 42 4 Estate 1991-1992
OPEL  ASTRA F Estate (51_, 52_) 1.7 D 1700 44 4 Estate 1992-1998
OPEL  ASTRA F Estate (51_, 52_) 1.7 TD 1700 50 4 Estate 1994-1998
OPEL  ASTRA F Estate (51_, 52_) 1.7 TDS 1686 60 4 Estate 1991-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.4 Si 1389 60 4 Hatchback 1992-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.4 i 16V 1389 66 4 Hatchback 1996-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 1598 55 4 Hatchback 1995-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 Si 1598 74 4 Hatchback 1992-1994
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 i 1598 52 4 Hatchback 1993-1996
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 i 1598 55 4 Hatchback 1991-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.6 i 16V 1598 74 4 Hatchback 1994-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.7 D 1700 42 4 Hatchback 1991-1992
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.7 D 1700 44 4 Hatchback 1992-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.7 TD 1700 50 4 Hatchback 1994-1998
OPEL  ASTRA F Hatchback (53_, 54_, 58_, 59_) 1.7 TDS 1686 60 4 Hatchback 1991-1998
OPEL  ASTRA F Van (55_) 1.6 i 1598 55 4 Box 1991-1993
OPEL  ASTRA F Van (55_) 1.6 i 1598 52 4 Box 1993-1996
OPEL  ASTRA F Van (55_) 1.7 D 1700 44 4 Box 1992-1999
OPEL  ASTRA F Van (55_) 1.7 D 1700 42 4 Box 1991-1992
OPEL  ASTRA F Van (55_) 1.7 TD 1700 50 4 Box 1994-1999
OPEL  COMBO (71_) 1.2 1195 33 4 Box 1994-2001
OPEL  COMBO (71_) 1.4 1389 44 4 Box 1994-2001
OPEL  COMBO (71_) 1.4 1389 60 4 Box 1994-2001
OPEL  COMBO (71_) 1.7 D 1686 44 4 Box 1994-2001
OPEL  CORSA A Hatchback (93_, 94_, 98_, 99_) 1.4 Si 1389 60 4 Hatchback 1991-1993
OPEL  CORSA A Hatchback (93_, 94_, 98_, 99_) 1.6 GSI 1598 72 4 Hatchback 1989-1993
OPEL  CORSA A Hatchback (93_, 94_, 98_, 99_) 1.6 GSI 1598 74 4 Hatchback 1988-1992
OPEL  CORSA A Hatchback (93_, 94_, 98_, 99_) 1.6 GSI 1598 55 4 Hatchback 1988-1992
OPEL  CORSA A Hatchback (93_, 94_, 98_, 99_) 1.6 GSI CAT 1598 74 4 Hatchback 1992-1993
OPEL  CORSA A TR (91_, 92_, 96_, 97_) 1.4 S 1389 53 4 Saloon 1989-1993
OPEL  CORSA B (73_, 78_, 79_) 1.2 i 16V 1199 48 4 Hatchback 1998-2000
OPEL  CORSA B (73_, 78_, 79_) 1.4 Si 1389 60 4 Hatchback 1993-2000
OPEL  CORSA B (73_, 78_, 79_) 1.4 i 1389 44 4 Hatchback 1993-2000
OPEL  CORSA B (73_, 78_, 79_) 1.4 i 16V 1389 66 4 Hatchback 1994-2000
OPEL  CORSA B (73_, 78_, 79_) 1.4 i 16V 1389 63 4 Hatchback 1997-2000
OPEL  CORSA B Box (73_) 1.4 i 1389 44 4 Box 1999-2000
OPEL  KADETT E (39_, 49_) 1.6 D 1598 40 4 Saloon 1984-1989
OPEL  KADETT E (39_, 49_) 1.6 S 1598 60 4 Saloon 1986-1991
Our advantage:

1. Great experience: have been in brake disc rotors field for more than 10years,served more than 2300 dealers;

2. Various products: we total have more than 1200 types of brake disc rotors, cover each vehicle system;

3. OEM,ODM accepted: we can produce brake disc rotors according to your requirement;

4. Low MOQ: only 200pcs/each, this quantity is economic and practical for you too;

5. Advanced technology: we have advanced production lines and many experienced technicians;

6, Good Quality: We have strict quality control system under ISO9001,Good reputation in the brake disc rotors market;

7, One stop Services: We treat clients as friend,and we also can supply brake shoes,brake pads,brake linings and ignition coils,it is convenient for your one stop purchase.

Packaging & Shipping

PACKING-brake disc rotors:

1,Inner box:

   1).In general,if your quantity of each type is up to 1000sets,we can supply the color packing according to your requirements(if it is a brand,you must provide the authorization to us).

   2).If you quantity of each type is less than 1000sets,we only can supply the neutral packing,this will reduce your purchase cost;

2,Outer box:

   In general we supply the neutral carton box with shipping mark;

3,Pallet packing:

SHIPPING-brake disc rotors:

   Ocean shipping,FCL or LCL.

CONTAINER SIZE TABLE:

MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA brake disc rotors

Factory pictures:

MDC322 90121445 96574633 90008032 90008006 90511111 569031 569054 for OPEL CORSA ASCONA brake disc rotors

Buying Guides

General Order Information:

We take great pride in our work and in the wide variety of products that we offer-brake pads≥1800 models,brake disc rotors≥1200 models,brake shoes≥800 models,brake linings≥600 models,ignition coils≥700 models.Our products have been sold all over the world with the good quality with reasonable price.

Check below for more information on placing an order:

1. Please make sure the OE NO. and technology requirements of these auto parts which you want to order.

2. Confirm the price, payment term,packaging,delivery time etc.

3. We will send the Proforma Invoice for your confirmation.

4. Customer make the payment for deposit and send us Bank remittance.

5. We will arrange the production asap after receipt of the deposit.

6. Middle Production,we will send photos to show the production status which you can see the production process of your order.

7. End Production-Mass production products photos would be sent to you for approval.

8. Clients make payment for balance and we will deliver these goods .

9. Order can be say “finish” when you receive the goods and satisfy with them .

10. Feedback to us about the quality , service, market feedback and suggestion. we will go through all question with you.



FAQ

Q1: What’s your main products?

A: Our main products are brake pads, brake discs,brake shoes,brake linings and ignition coils.

Q2: What’s your payment terms?

A:In general payment terms is T/T ,L/C and The Western Union,Paypal etc.

Q3: Can you provide some samples?

A: Yes we can,but you need pay the freight charge.

Q4: What’s your MOQ?

A: Our minimum order quantity of opel ascona brake disc rotors is 200 pcs.

Q5: What’s your delivery time ?

A: The delivery time is 35 days or so,according to your quantity and your order structures.
