Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > High Speed USB 2.0 Extension Cable AM/AF

High Speed USB 2.0 Extension Cable AM/AF

Name: High Speed USB 2.0 Extension Cable AM/AF
Brand: QXH-Tech
SKU: 117651945

High Speed USB 2.0 Extension Cable AM/AF thumbnail-1

High Speed USB 2.0 Extension Cable AM/AF photo-1

US$ 0.3 - 0.65 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Brand Name:

QXH-Tech

Model Number:

Q-USB2.0-0002

Place of Origin:

Guangdong, China

Contact Supplier Request Quote Chat Now

Shenzhen Qiangxinhong Technical Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN/HONGKONG

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name QXH-Tech

Model Number Q-USB2.0-0002

Place of Origin Guangdong, China

Interface Type USB

Use Other, computer extension connection, Computer

Specifications

1.USB extension cable
2.UL2725 28AWG,copper
lor,length is your option
4.High speed to 480Mbps
5.CE&UL&RoHS

High speed USB 2.0 extension cable AM/AF

USB extension cable

Specifications

USB 2.0 cable
1.USB 2.0 AM TO AF cable
2.Data transfer rate up to 480Mbps
3.28AWG+28AWG Conductor
4.Rated voltage:30V

USB 2.0 Cable

USB 2.0 extension cable

High speed USB 2.0 cable (compliant with USB 1.1,USB 2.0)

One 28AWG twisted pair(data) plus two power conductors

Features:

1. Active USB cable increases the length of your device cable without signal and power output loss
2. Built in signal booster
3. Cable length can be extended up to 80 feet by chaining 6 of these active cables
4. USB Extension cables create an easily assessable USB port
5. Both low and high speed USB devices will function equally well with this USB extension cable
6. Fully compatible with USB 2.0 Hi-Speed USB specification

Electrical:
100% open & short test
Hi-Pot: DC 300V 10ms
Insulation Resistance: 10M OHM /300V Min.
Contact Resistance: 0.01 OHM Max.
Shield up to 65% braid.
Working Temperature: -25oC ~ +85oC
Mechanical:
Over mold: PVC 70Pa UL94V-0 Black
Pre mold: PE Low Density
Contact: Copper Alloy.
Insertion Force: 35 N Max.
Withdraw Force: 10 N Min

Packing:
Polybag, headcard, blister, Slide card,giftbox ,according to clients' requirement.

After-sales service:
1).Our slogan is "keeping in touch with our customers with parts of quality and benefiting our customers with best service.
2).Our promise, so long as product quality has question, upon test and find out if they are our fault, we can exchange or resupply to you for free with my company connection.
